Transmission Structures - China
price: contact company for price
Transmission structures, commonly referred to as transmission towers or electricity pylons, are integral components of the electrical power transmission system.
These structures are designed to support overhead power lines that carry electrical energy across vast distances, from power generating stations to substations and consumers.
Understanding the different types of transmission structures and their roles helps in appreciating the complexity and engineering behind modern power distribution networks.
Product transmission structures
Shape lattice
Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².
OR Q420 Q460 ASTM A572 GR65, GR50, SS400
Electric Voltage 10kv, 11kv, 32kv, 33kv, 35kv, 65kv, 66kv, 90kv, 92kv, 110kv, 115kv, 132kv, 220kv, 230kv, 300kv, 320kv, 330kv, 345kv, 380kv, 400kv 500kv, 750kv, 765kv, 800kv, 850kv, 1000kv, 1100kv
Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.
connection bolt connection
Standard ISO 9001: 2008
Height: below 60 meters
Surface treatment: galvanization and color painted
Welding Standard AWS (American Welding Society ) D 1.1
Production Process Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages
Packages Packing with plastic paper, steel box or according to client’s request.
Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.
Transmission tower design adheres to ASCE/SEI standards.
Telecommunication tower design follows ANSI/TIA-222 standards.
We are not just manufacturers and suppliers, but also your technical support and partners.
Company Contact:
- Posted By: Deshi Industry
- Phone: +865368666318
- Address: No.322 YinfengRoad, weifang , china , China
- Email:
- Website: https://deshiindustry.com
Published date: June 17, 2024
- Business Description: Design, Manufacturing, and Construction Support for Transmission Towers, Telecom Towers, Steel Structure Buildings, Weather tower, Observation Towers, Microwave Towers, and Lightning Towers.
