Transmission Lattice Tension Tower - China

A Transmission Lattice Tension Tower, also known as a strain tower, is another specialized type of structure used in electrical power transmission networks.

These towers are designed to withstand not only the vertical loads of the transmission lines but also significant horizontal forces.

Tension towers are typically used in scenarios where the transmission line spans long distances without any intermediate support or where it needs to navigate significant geographical obstacles, such as valleys or rivers.

The design of a tension tower often includes heavier and sturdier construction compared to suspension towers.

They feature a lattice structure made of steel, which offers high strength and flexibility while minimizing weight and material cost.

The tower’s base is usually broader and anchored deeply into the ground to ensure stability against the tension of the wires pulling in various directions.

This design helps maintain the integrity of the power line pathway, ensuring safe and reliable power transmission over challenging terrains and long spans.

Product Transmission Lattice Tension Tower

Shape lattice

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 10kv, 33kv, 35kv, 65kv, 66kv, 110kv, 132kv, 220kv, 230kv, 330kv, 380kv, 500kv, 750kv, 800kv, 1000kv, 1100kv

MOQ FCL

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection bolt connection

Standard ISO 9001: 2008

Height: below 60 meters

Surface treatment: galvanization and color painted

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, bundle, wooden box or steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
