Transmission Lattice Dead End Tower - China

A Transmission Lattice Dead-end Tower, also known as a terminal tower, is a type of structure used in electrical power transmission lines.

These towers are specially designed and built to handle the mechanical loads that occur at the end of a transmission line segment or where the line must make a significant directional change.

Unlike suspension towers, which primarily support the weight and tension of the transmission lines along straight sections, dead-end towers are robust and have a more substantial build to withstand the increased tension and forces exerted by the cables ending or changing direction at these points.

Product Transmission Lattice Dead-end Tower

Shape lattice

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 10kv, 33kv, 35kv, 65kv, 66kv, 110kv, 132kv, 220kv, 230kv, 330kv, 380kv, 500kv, 750kv, 800kv, 1000kv, 1100kv

MOQ FCL

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection bolt connection

Standard ISO 9001: 2008

Height: below 60 meters

Surface treatment: galvanization and color painted

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, bundle, wooden box or steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
