Terminal Transmission Tower - China

A terminal transmission tower, also known as a dead-end tower, is a crucial component of an electrical transmission network.

It is specifically designed to handle the mechanical loads associated with the termination of a transmission line or when a line needs to make a significant directional change.

These towers are typically more robust than standard line towers due to the greater forces exerted by the cables ending or changing direction.

Product terminal transmission tower

Shape lattice

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 10kv, 11kv, 32kv, 33kv, 35kv, 65kv, 66kv, 90kv, 92kv, 110kv, 115kv, 132kv, 220kv, 230kv, 300kv, 320kv, 330kv, 345kv, 380kv, 400kv 500kv, 750kv, 765kv, 800kv, 850kv, 1000kv, 1100kv

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection bolt connection

Standard ISO 9001: 2008

Height: below 60 meters

Surface treatment: galvanization and color painted

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
