Steel Tubular Electric Poles - China

steel tubular electric pole is specifically engineered for electrical infrastructure, such as carrying overhead power lines.

These poles are popular in electrical networks due to their durability, strength, and ease of maintenance.

Here’s a detailed overview: Characteristics of Steel Tubular Electric Poles

Material: These poles are constructed from high-strength steel.

The steel is typically galvanized to protect against corrosion, making it more durable and suitable for outdoor environments.

Shape: As the name suggests, these poles are tubular, providing a uniform diameter throughout or sometimes tapering towards the top.

The tubular design offers excellent resistance to bending and torsional forces.

Durability: Steel’s inherent strength provides significant resistance to physical stresses, weather conditions, and environmental impacts.

The galvanization process further ensures longevity by preventing rust and decay.

Load Capacity: They are designed to support substantial loads, making them ideal for both distribution and high-voltage transmission lines.

They can be equipped with various brackets and reinforcements to hold multiple cables, transformers, and other electrical components.

Advantages: Long Service Life: These poles can last for decades with minimal maintenance, primarily due to steel’s robustness and the protective galvanized coating.

Cost Efficiency: Though the initial investment might be higher compared to other materials like wood, the long lifespan and low maintenance costs render them cost-effective over time.

Recyclability: Steel is fully recyclable, which enhances the environmental sustainability of using steel tubular poles.

Ease of Installation: Despite their strength, these poles are relatively lightweight compared to solid poles, which simplifies transportation and installation.

They can be installed using standard lifting equipment.

Applications: Electrica l Power Distribution and Transmission: Used extensively in the distribution of electricity from substations to consumers and in the transmission of high-voltage power over long distances.

Utility Services: Besides electrical cables, they can also support ancillary utility infrastructures like street lighting and telecommunication lines.

Installation: The installation of steel tubular electric poles often involves digging a hole to a specified depth, placing the pole, and securing it with concrete or other stabilizing materials.

Depending on the application, these poles might also be directly embedded into the ground.

Steel tubular electric poles are essential for modern electrical infrastructure, offering a robust, reliable, and efficient solution for managing and distributing electrical power across various regions.

Product steel transmission pole

Shape Polygonal or Conical

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 4kv, 6kv, 10kV, 11kv, 33kv, 32kv, 35kv, 65kv, 66kv, 110kv, 132kv, 135kv, 220kv, 230kv, 330kv, 380kv etc.

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection Slip joint, flanged connected

Standard ISO 9001: 2008

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, bundle, wooden box or steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
