Single Circuit Transmission Tower - China

A single circuit transmission tower is designed to support a single set of three-phase electrical conductors or power lines.

These towers are a fundamental component of electrical transmission networks, carrying electricity over long distances from power stations to substations or distribution areas.

Single circuit towers are commonly used in areas where the power demand is relatively low or where right-of-way issues limit the space available for larger towers.

Key Features of Single Circuit Transmission Towers:

1 - Structure: These towers are typically more slender and less robust than their double circuit counterparts.

They consist of a single vertical structure with cross-arms to support one set of three-phase conductors.

2 - Design: The design of single circuit towers often focuses on cost-effectiveness and land use efficiency.

The towers can vary in height and design depending on the voltage of the lines they carry and the environmental conditions of their location.

3 - Material: Most single circuit towers are made of steel, which provides durability and strength.

In some cases, especially for lower voltage lines, lighter materials such as aluminum or a combination of steel and aluminum may be used.

Product single circuit transmission tower

Shape lattice

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 10kv, 11kv, 32kv, 33kv, 35kv, 65kv, 66kv, 90kv, 92kv, 110kv, 115kv, 132kv, 220kv, 230kv, 300kv, 320kv, 330kv, 345kv, 380kv, 400kv 500kv, 750kv, 765kv, 800kv, 850kv, 1000kv, 1100kv

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection bolt connection

Standard ISO 9001: 2008

Height: below 60 meters

Surface treatment: galvanization and color painted

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
