Single Circuit Monopole Transmission Line Tower - China

A “single circuit monopole transmission tower” is a type of tower used for the transmission of electrical power with a design that supports only one electrical circuit.

These towers are characterized by their single-pole structure, which is sleek and less obtrusive compared to other types of transmission towers like the lattice design.

The single-pole design not only helps in reducing the land footprint but also minimizes the visual impact on the environment.

This makes them particularly suitable for settings where aesthetic considerations are important or where space is limited.

Single circuit monopoles are efficient for transmitting power over shorter distances and are often used in urban areas where space constraints are significant.

Product Single circuit monopole transmission line tower

Shape Polygonal or Conical

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 4kv, 6kv, 10kV, 33kv, 35kv, 65kv, 66kv, 110kv, 132kv, 220kv, 230kv etc.

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection Slip joint, flanged connected

Standard ISO 9001: 2008

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, bundle, wooden box or steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
