Metal Power Pole - China

A metal power pole is a type of utility pole made primarily from metals like steel, used extensively in electrical distribution and transmission lines.

These poles are valued for their durability, strength, and resistance to environmental factors, making them a robust choice for utility infrastructure.

Key Features of Metal Power Poles Material: The most common metals used for these poles are steel and aluminum.

Steel poles are often galvanized or coated to prevent corrosion, while aluminum poles are naturally resistant to corrosion and lighter in weight.

Durability: Metal poles are extremely durable and can withstand harsh weather conditions, including high winds, heavy snow, and ice accumulation.

The life expectancy of metal poles can be significantly longer than that of wooden poles, often exceeding 50 years with minimal maintenance.

Strength and Load Capacity: Metal poles have a high strength-to-weight ratio, allowing them to support heavy loads.

They can be designed to carry multiple power lines, transformers, and other equipment necessary for both high and low voltage power transmission and distribution.

Maintenance: These poles require less maintenance compared to wooden poles, as they do not suffer from issues like rot, insect damage, or woodpecker holes.

Their longevity and low maintenance needs make them a cost-effective option over the long term.

Installation: Metal poles are generally heavier than wooden ones, which may require specialized equipment for transportation and installation.

However, their modular design often allows for quicker and easier installation compared to traditional wooden poles.

Product metal power pole

Shape Polygonal or Conical

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 4kv, 6kv, 10kV, 11kv, 33kv, 32kv, 35kv, 65kv, 66kv, 110kv, 132kv, 135kv, 220kv, 230kv, 330kv, 380kv etc.

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection Slip joint, flanged connected

Standard ISO 9001: 2008

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, bundle, wooden box or steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
