Guyed Lattice Transmission Tower - China

A guyed lattice transmission tower is a type of electrical transmission tower characterized by its lattice structure and additional guy wires for support.

These towers are commonly used in power transmission networks to carry electrical conductors over long distances.

Key Features of Guyed Lattice Transmission Towers:

Lattice Structure: Guyed lattice towers consist of a framework of intersecting steel angles or tubes welded or bolted together to form a lattice pattern.

This lattice structure provides strength and stability while minimizing material usage, making it lighter and more cost-effective compared to solid structures.

Guy Wires: Unlike self-supporting lattice towers, guyed lattice towers are stabilized by additional guy wires anchored to the ground.

These guy wires provide extra support against lateral forces such as wind or ice loads, allowing for taller tower designs with greater spans between supports.

Height and Span: Guyed lattice towers can be constructed to varying heights and spans depending on the requirements of the transmission line.

The use of guy wires enables the towers to achieve greater heights and longer spans while maintaining structural stability.

Installation and Functionality:

Installation: Erecting a guyed lattice tower involves assembling the lattice structure on-site and installing the guy wires anchored to the ground at specified locations.

The installation process requires careful planning and engineering to ensure proper alignment, tensioning, and stability of the guy wires.

Functionality: Guyed lattice towers are designed to support electrical conductors and associated hardware for power transmission.

The lattice structure provides the necessary strength to withstand vertical loads, while the guy wires resist lateral forces, preventing the tower from leaning or buckling under external pressures.

Benefits and Applications:

Cost-Effectiveness: Guyed lattice towers are generally more economical to build than self-supporting towers due to their lighter weight and reduced material requirements.

The use of guy wires allows for taller and longer-span structures without the need for excessively thick or heavy members.

Versatility: These towers can be used in a variety of terrain and environmental conditions, including flat plains, hilly regions, and coastal areas.

The flexibility in design and construction makes them suitable for both short and long-distance transmission lines.

Durability: The lattice structure of these towers provides inherent resistance to wind, ice, and other environmental factors, while the guy wires enhance stability and resilience against dynamic loads.

Challenges and Considerations:

Maintenance: Guyed lattice towers require regular inspection and maintenance of the lattice structure, guy wires, and anchor points to ensure structural integrity and reliability.

Land Use: The installation of guyed lattice towers requires sufficient space for anchoring the guy wires, which may impact land use and require rights-of-way agreements with landowners.

Guyed lattice transmission towers play a vital role in electrical power transmission infrastructure, providing a cost-effective and reliable solution for carrying high-voltage electrical lines over long distances.

Their combination of strength, stability, and versatility makes them a preferred choice in many transmission projects around the world.

Product guyed lattice transmission tower

Shape lattice

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 10kv, 11kv, 32kv, 33kv, 35kv, 65kv, 66kv, 90kv, 92kv, 110kv, 115kv, 132kv, 220kv, 230kv, 300kv, 320kv, 330kv, 345kv, 380kv, 400kv 500kv, 750kv, 765kv, 800kv, 850kv, 1000kv, 1100kv

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection bolt connection

Standard ISO 9001: 2008

Height: below 60 meters

Surface treatment: galvanization and color painted

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
