Galvanised Power Pole - China
price: contact company for price
A galvanized power pole is a type of utility pole treated with a protective zinc coating to prevent rust and increase durability, commonly used in electrical distribution and transmission systems.
This treatment is especially valuable in extending the lifespan of steel poles exposed to harsh environmental conditions.
Key Features of Galvanized Power Poles
Material and Coating: These poles are primarily made of steel and coated with a layer of zinc through a process called galvanization.
The zinc acts as a protective barrier against moisture and environmental elements that cause corrosion.
Durability and Resistance: The zinc coating provides excellent resistance to corrosion, which is crucial for metal structures exposed to the outdoors.
This significantly extends the service life of the poles, as they can withstand rain, snow, and high humidity without rusting.
Maintenance: Galvanized poles require less maintenance compared to non-galvanized or wooden counterparts, as the zinc coating minimizes wear and tear from weather conditions.
This makes them a cost-effective solution over their operational lifespan.
Load Capacity: Like other steel poles, galvanized poles are capable of supporting heavy loads.
They are strong enough to carry multiple high-voltage power lines, transformers, and other equipment necessary for modern electrical grids.
Advantages: Longevity: The protective zinc coating can significantly prolong the life of steel poles, with lifespans typically ranging from 40 to 70 years depending on environmental conditions.
Cost-Effective ness: The combination of durability, reduced maintenance, and extended lifespan makes these poles a cost-effective choice for utility companies.
Eco-Friendly: Steel is fully recyclable, and using galvanized steel helps reduce the frequency of replacements, lowering the environmental impact over time.
Applications: Electrica l Distribution: Commonly used to distribute electricity from substations to residential and commercial areas.
Telecommunications: Often used to support cables and equipment for telephone and internet services.
Street Lighting: Can be used to mount street lights due to their robust structure and stability.
Installation: Installing a galvanized power pole typically involves digging a hole to the appropriate depth, setting the pole in place, and securing it with concrete or other stabilizing materials.
For taller or heavier poles, cranes or special machinery may be required to assist with the installation.
Galvanized power poles are essential in building and maintaining reliable electrical and utility networks, especially in regions prone to inclement weather.
Their robustness and longevity make them a preferred choice for infrastructure projects aimed at long-term efficiency and sustainability.
Product galvanised power pole
Shape Polygonal or Conical
Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².
OR Q420 Q460 ASTM A572 GR65, GR50, SS400
Electric Voltage 4kv, 6kv, 10kV, 11kv, 33kv, 32kv, 35kv, 65kv, 66kv, 110kv, 132kv, 135kv, 220kv, 230kv, 330kv, 380kv etc.
Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.
connection Slip joint, flanged connected
Standard ISO 9001: 2008
Welding Standard AWS (American Welding Society ) D 1.1
Production Process Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages
Packages Packing with plastic paper, bundle, wooden box or steel box or according to client’s request.
Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.
Transmission tower design adheres to ASCE/SEI standards.
Telecommunication tower design follows ANSI/TIA-222 standards.
We are not just manufacturers and suppliers, but also your technical support and partners.
Company Contact:
- Posted By: Deshi Industry
- Phone: +865368666318
- Address: No.322 YinfengRoad, weifang , china , China
- Email:
- Website: https://deshiindustry.com
Published date: June 12, 2024
- Business Description: Design, Manufacturing, and Construction Support for Transmission Towers, Telecom Towers, Steel Structure Buildings, Weather tower, Observation Towers, Microwave Towers, and Lightning Towers.
