Steel Rail - China

GB11264-89 Railway Rail

Detailed Images Rail Specification

1 - Light rail of GB11264-89 Standard, YB222-63 Standard

Size: 6kg, 9kg, 12kg, 15kg, 22kg, 30kg, 8kg, 18kg, 24kg.

Material: 55Q/Q235b

Standard: GB11264-89 standard, YB222-63 standard

Length: 6-12m 2 - Heavy Rail of GB2585-2007 Standard

Size: 38kg, 43kg, 50kg.

Material: U71mn/50mn

Standard: GB2585-2007

Length: 12.5m, 25m 3 - Crane Rail of YB/T5055-93 Standard

Size: QU70\QU80\QU100\QU120 -

Material: U71mn

Standard: YB/T5055-93

Length: 12m 4 - South African Standard Steel Rail

Size: 15kg, 22kg, 30kg, 40kg, 48kg, 57kg.

Standard: ISCOR

Length: 9-25m 5 - Australian Standard Steel Rail

Size: 31kg, 41kg, 47kg, 50kg, 53kg, 60kg, 66kg, 68kg, 73kg, 86kg, 89kg.

Standard: As 1085

Length: 8-25m 6 - UIC860-O Standard Steel Rail

Size: UIC50, UIC54, UIC60 -

Standard: UIC860-0, EN-13674-1

Material: 900A/1100

Length: 12-25m 7 - BS11-1985 Standard Steel Rail

Size: BS50'O', BS60A, BS60R, BS70A, BS75A, BS75R, BS80A, BS80R, BS90A, BS100A, BS113A.

Standard: BS11-1985

Length: 8-25m 8 - JIS E 1103/1101 Standard Steel Rail

Size: 15kg, 22kg, 30A, 37A, and 50N, CR73, CR100.

Standard: JIS E1103-93/JIS E1101-93

Material: According to JIS

Length: 9-10m 9 - American Standard Steel Rail

Size: ASCE25, ASCE30, ASCE40, ASCE60, ASCE75, ASCE85, ASCE90, ASCE115, ASCE136, ASCE175.

Standard: ASTM, AREMA

Length: 6-12m, 12-25m

10 - DIN Crane Steel Rail

Size: A45, A55, A65, A75, A100, A120.

Standard: DIN536

Material: U71MN, 900A

Length: 9m-12m

Production Export Project Related Products

Hanzi can supply a full set railway fastening including rail for you: Hanzi Certificates

ISO Certified Company

Hanzi Industrial established a comprehensive Quality Assurance (Q.

A) System.

It is regularly tested, approved and audited by independent Q.

A auditor.

This complies with internationally standards ISO 9001: 2008.



Company Information

Hanzi Industrial Shanghai Co., Ltd specializes in manufacturing railway accessories.

As an ISO certified company, we have a large selection of track accessories and tools to fit your needs: Steel Rail, Rail Clip, Fishplate(Joint Bar), Baseplate, Rubber Pad, Rubber Crossing Plates, Screw Fasteners, Rail Clamps, Rail Anchors, Turnout, Wagons, etc.

As an Alibaba Trade Assurance Member, it means you will get 100% payment refund up to Trade Assurance Amount if we can’t meet agreed delivery and quality terms contained in the contract.

It is a free service for both of us.

Thus you can place order to us with confidence.

In order to ensure better quality, the steel rails have to undergo many tests, including chemical composition test, tensile strength test, hardness test and the drop weight test.
