Outdoor Playground Open Type Track Train By Diesel 120 Seats Dst01 7c 120b - China
price: 249000.00 Dollar US$
1 - Feature and advantage: Theme Park Mini Track Train/ Locomotive with 120 Seats Manufacturer for Amusement Rides Mini Diesel Track Train with High quality & conpetitive price you.
Customer is welcome to visit our new showroom and factory located in Wuhan City, China.
2 - Specifications DST01-7C-120B Open-type Sightseeing Mini Train Gauge: 762/900/1435mm
Marshalling: locomotive +coal water truck + carriage*3
Speed: 10km/h
Crew: 40 *3=120
Mat limit slope: 30 per thousand
Restriction curve radius: 30m
Power: diesel generating set (Cummins) 2.1 Ambient conditions and vehicle parameters 1) Project location height is not more than 2000 meters above sea level.
2) The air temperature is between -10 and 40 degree.
3) Electronic components must not be activated without dehumidification in relative humidity greater than 95% or condensation.
4) Vehicles should be able to withstand the invasion of wind and sand and the resistance to salt spray
5) Line gauge: 762mm
6) Limiting slope: 30 ‰ (reduction calculations for curves)
7) The radius of the line longitudinal curve is 200m
8) Line minimum curve radius 40m, difficult area 30m
2.2 Vehicle parameters 1) Style: European classical (see attachment renderings)
2) Gauge: 762mm
3) Formation mode: locomotive + coal water truck + compartment + compartment + compartment + compartment
4) Group size 38.2m (length) x 1.9m (width) x 2.8m (height)
5) Passenger Capacity: 128 seats
6) Limit curve radius: 40m, difficult section (station) 30m
7) Limit slope: <= 30‰, curve section needs to perform this calculation
8) Speed: 0-10km/H
9) Emergency braking distance: <4m
10) Guided tour system: The host is located on the bridge of the locomotive, the audio is located in each compartment, playing background music, site broadcast, temporary voice notification
11) Overall dimensions mm: 10170 (length) * 2000 (width) * 2830 (high)
12) Driver's seat: seated 2 seats
13) Structure: Q235 profile, steel plate welding
14) Locomotive axis sequence: 2-2-0
15) Drive system:
16) Coal Waterwheels: Power Bogies
17) Drive Motor : 7.5KW*4 Variable Frequency Motor
18) Speed control method: frequency conversion speed control touch screen + plc + inverter S curve acceleration vector control 19) Main power source: Cummins diesel generator set 80kw, Stanford generator
20) Braking system: Working brake: Regenerative braking (motor fed brake) Emergency, parking brake: Electropneumatic braking
21) Forward driving video (improving driver's view)
22) EffectSmokestack effect of continuous smoke \steam whistle\copper bell (12 inches)
23) Overall dimensions mm: 6.2 (L) * 1900 (W) * 2800 (H)
24) Cabin form: semi-open type, on both sides of the car, with car steps
25) Minimum height of passenger area: 1800mm
26) Floor height: 600mm (rail surface)
27) Step height: 400mm (rail surface)
28) Structure: Q235 profile, sheet metal welding, roof FRP composite
29) Running system: Bogie form (with automatic emergency braking)
30) Renovation: Roof interior wallsolid wood buckle + wood paint (6 degrees) Floor: bamboo plastic plate + pattern aluminum
31) Seats: 32 seats (wooden seats) Lamps: Antique LED Ceiling Lights Sound: Wood Effect Ceiling Speakers
32) Car side railing: solid wood (weathering wood oil 6 degrees)
33) Side door: 8 sided, FRP composite (inside solid wood) End window: Solid wood panning window
34) Urveillance: Camera (recording) 2pcs/car
35) European metal corner flower on the roof: 16 handrails on and off: 304 stainless steel
36) Weather curtain: transparent shutter (removable, fast retractable)
Company Contact:
- Posted By: Wuhan Dising Technologies Co.,Ltd
- Phone: +86 18971364166
- Address: No.331,Minzu Avenue,East Lake High-Tech Zone,Wuhan,China, Wuhan city, Hubei , China
- Email:
- Website: https://www.cndising.com/en/
Published date: November 15, 2018
- Business Description: Wuhan Dising Technologies Co., Ltd
We are an integrated enterprise mainly engaged in the research and development, production, sales, and service of green environmental protection vehicles.
It is also a leader in the national tourism train industry.
Products & Services
"DISING TECH" adheres to the concept of "Green and Beautiful Earth" and responds to the call to strengthen the construction of ecological civilization.
We are also continuously developing and introducing new technology.
Dising the company has large-scale amusement equipment "Slow Rail Transit and Sightseeing Train" , Tourist train, Imitation steam locomotives, trams , trackless Sightseeing Train, amusement trains series, electric vehicles and Yacht series and other leisure technology, new energy products!
And provide tourism and Tourist train, sightseeing railway line survey, exploration, design, railway laying, transfer operations and other services.
