Sungraf Corrugated Graphite Tape - China

Corrugated graphite tapes are made from graphite rolls, using high precision lathe to cut them in tapes and then have them corrugated by specialized pattern roller.

Compared with traditional graphite, corrugated tapes have higher precision and less self damage.

Technical Data Sheets: Width (mm)

2.5- 1000

Thickness (mm )

0.1- 0.8

Length (mm )

1- 200

Tolerance of Thickness ( mm )

±0.3

Carbon Content %

95- 99.5

Tensile Strength (Mpa )

≥ 4.5

Working Temperature (℃ )

-200- 650 ( Under Oxidizing Condition ) -200~ +3000°C(non-Oxidizing situation)

PH Value

0- 14

Density (g/ cm3 )

0.7- 1.3

Tolerance of Density (g/ cm3 )

± 0.5 Applications: 1 - Used as a gasket strip for vessels and flanges

2 - Used in heat exchangers, boilers, pipelines, furnace doors, box covers, etc.

3 - As coating on both side of kammprofile gaskets.

4 - Graphite tape filler is used for spiral wound gasket, In-situ pump and valve gland packing

5 - Filler for metal jacketed type gaskets
