Vapor Pressure Analyzer For Liquefied Petroleum Gas - China

Scope

Vapor pressure of liquefied petroleum gas analyzer used by GB/T6602-89 "Determination of vapor pressure liquefied petroleum gas (LPG Act)" under certain pressure meter and 37.8 ~ 70ºC temperature test to measure the vapor pressure of liquefied petroleum gas ( gauge pressure).

The instrument applies to a boiling point above 0ºC, hydrocarbon content of less than 5% in 37.8ºC, the vapor pressure of not more than 1550Kpa LPG Features

The instrument consists of a vapor pressure test, constant temperature water bath, temperature control, time control instrument, an electric mixer, pressure gauge.

1 - The basic composition of the vapor pressure tester for the upper chamber and the lower chamber, the upper chamber and the lower chamber volume ratio of 2 ± 0.03, respectively, and 4 ± 0.05.

2 - The water bath for interlayer insulation box filled with insulation materials installed in the main, auxiliary heater and an electric mixer in a water bath.

Water bath is installed above the support plate placement vapor pressure tester, at one time were placed two vapor pressure tester.

3 - Temperature control, time control instrument: digital display, measuring range of 0 to 99.9 °C, a temperature control accuracy: ± 0.1°C, time consciousness: 0~999S to alarm.

4 - The mixing apparatus: (leaf), the stirring shaft by the stirring motor.

5 - The pressure gauge: Range: 0 ~ 2.5Mpa.

Level: 0.4 Technical Parameters

1 - The vapor pressure of the test device by the upper chamber and the lower chamber consists of:

Upper chamber: diameter 51 ± 3mm, length 254 ± 3mm (inner wall)

Lower chamber: 33 1/3% of the upper chamber and the lower chamber of a volume ratio of 2 ± 0.03

The volume ratio of 20% of the upper chamber and the lower chamber 4 ± 0.05

2 - Constant temperature water bath: Main heating power: 1500W

Auxiliary heating power: 800W

Temperature control accuracy: ± 0.1°C

3 - Mixing motor power: 40W 4 - The mixing motor speed: 1400 rev / min

5 - The vapor pressure tester leakage pressure greater than 3.5MPa

6 - The pressure gauge: 0.4 standard gauge BS150mm.

Specifications: 0 ~ 2.5MPa
