Transformer Board H4 - China

H4 Transformer Board Production Description:

1) Pre-compressed Pressboard, with Quality Standard: IEC60641-3-1: 1992/GB/T 19264.3-2003

2) Thickness: 1.0mm, 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm, 5.0mm, 6.0mm, 7.0mm, 8.0mm

3) Material: 100% unbleached sulfate pulp imported from Canada, Russia.

4) High density, high mechanical strength, high electric strength and low compression index.

5) 4400mm*2200, 6300mm*3200mm and customized size Transformer pressboard

H4 Transformer Board Technical Specifications:

Item Unit Specification Standard

Thickness mm ≤1.0mm ±6%

≤1.5mm-1.6mm ±6%

≤2.0mm-3.2mm ±4%

4.0mm ±4%

≥5.0mm ±4%

Density g/cm3 ≤1.6mm 1.05-1.20

>1.6mm-3.0mm 1.15-1.25

>3.0mm-6.0mm 1.20-1.30

>6.0mm-8.0mm 1.20-1.30

Moisture % 1.0mm-8.0mm ≤6.0%

Tensible Strength MD MPa ≤1.6mm ≥105

>1.6mm-3.0mm ≥110

>3.0mm-6.0mm ≥115

>6.0mm-8.0mm ≥115

CD ≤1.6mm ≥80

>1.6mm-3.0mm ≥90

>3.0mm-6.0mm ≥90

>6.0mm-8.0mm ≥90

Elongation MD % 1.0mm-8.0mm ≥3

CD 1.0mm-8.0mm ≥4

Ash Content % 1.0mm-8.0mm ≤0.6

Shrinkage MD % 1.0mm-8.0mm ≤0.5

CD 1.0mm-8.0mm ≤0.7

TD 1.0mm-8.0mm ≤5.0

PH of Aqueous Extract / 1.0mm-8.0mm 6.0-8.0

Conductivity of Aqueous Extract Ms/m ≤1.6mm ≤4.5

>1.6mm-3.0mm ≤5.0

>3.0mm-6.0mm ≤6.0

>6.0mm-7.0mm ≤7.0

>7.0mm-8.0mm ≤8.0

Compression % ≤1.6mm ≤10.0

>1.6mm-3.0mm ≤7.5

>3.0mm-6.0mm ≤5.0

>6.0mm-8.0mm ≤4.0

Recoverable factor after Compression % ≤1.6mm ≥50

>1.6mm-3.0mm ≥55

>3.0mm-6.0mm ≥55

>6.0mm-8.0mm ≥55

Electrical Strength (In air) KV/mm ≤1.6mm ≥13.0

>1.6mm-3.0mm ≥13.0

>3.0mm-6.0mm ≥13.0

>6.0mm-8.0mm ≥12.0

Oil Absorption % ≤1.6mm ≥11.0

>1.6mm-3.0mm ≥9.0

>3.0mm-6.0mm ≥7.0

>6.0mm-8.0mm ≥7.0

Electrical Strength (In Oil) KV/mm ≤1.0mm ≥45

≥1.5mm-1.6mm ≥45

>1.6mm-2.0mm ≥35

>2.0mm-2.5mm ≥35

>2.5mm-3.0mm ≥35

>3.0mm-6.0mm ≥35

>6.0mm-8.0mm ≥35

PLY Bond Visual Measurement Obvious rough, fibers coming out when tearing

Cutting Size Tolerance mm 1.0mm-8.0mm ±10mm

Inclination Tolerance mm 1.0mm-8.0mm ±10mm

Usage:

Mainly used in oil-immersed transformer as insulation material, also used in reactor mutual inductance ware, electric device and etc.

Package:

Wrapped with vinyl film for waterproof, weaved material, then core paper packed, and wooden pallets.
