Juice Filling Plant With Bottle Sterilizer And Cip Cup - China

Key words: juice filling plant, juice filling machine, juice filling plant

QUICK DETAILS:

Model: CCGF24-24-24-8

Brand: FILL-PACK

Power: 7.2kw

Voltage: 380V 3PH 50HZ or customized

Driven force type: Electrical

juice bottling machine suppliers: FILL-PACK

Automation degree: Automatic

Dimension: 4100*2100*2100mm

Weight: 6500kg

Application: juice

Packing category: Bottles

Packing material: PET

Condition: New

FILL-PACK juice filling machine

PROPERTIES:

Capacity: 0-10000 BPH (0.5L)

Applicable bottle size: 0-2L

Key material: SUS304

Fuction: juice filling

Processing liquid: juice

Filling precision: +/- 1mm

Origin: ZhangJiaGang, China

After sales service: Engineers avaliable to service overseas

Qualification: CE, ISO9001-2008

The series JUICE FILLING PLANT is used in hot filling of juice, green tea, black tea, wulong tea and other beverage drink.

The machine integrates washing, filling, capping together.

The design is scientific and reasonable.

Its appearance is beautiful.

Its operation and maintenance is convenient.

The automation is high.

It is good equipment for choosing hot drink filling machine.

If you want to know the FILL-PACK juice filling machine price, please visit our website

The machine is adopt block bottle-neck hanging work state design, and be adopt filling valve rise-drop design.

It's be satisfy for 85°C hereinafter hot filling technology demand.

It's adpot person-machine interface touch-screen, PLC, transducer etc advanced control technology.

The drink touching part material parts is adopt the SUS304 stainless steel, The machine main motor, reducer, mostly axletree, pressurize parts and electricity ware element, gas drive element etc are adopt famous international manufacturer products.

Parameters: Model CCGF24-24-24-8

Capacity (B/H) 0-10000(500ml)

Bottle size Neck : φ50-100mm: Height: 150-32 0mm

Water Pressure 0.18-0.25Mpa

Water consumption(kg/h) 1000

Filling precision ＜+1MM

Air pressure 0.5Mpa

Air consumption 0.3m3/min

Weight(kg) 6500

Dimension(L*W*H) 4000*2100*2300mm
