Easy Cleaning 5t H Tubular Sterilizer With Gpm Standard - China
price: contact company for price
Key words: tubular sterilizer, juice sterilizer, tubular pasteurizer
Model: TS-5000
Brand: FILL-PACK
Power: 40kw
Voltage: 380V 3PH 50HZ or customized
Driven force type: Electrical
Automation degree: automatic
Application: juice sterilization
Condition: New FILL-PACK tubular sterilizer
PROPERTIES:
Volume: 5000L
Key material: SUS304
Fuction: juice sterilization
Sterilization way: steam heating
Working pressure: 0.6Mpa
Power: 40Kw
Steam consumption: 0.05kg/L
Heat exchange capacity: 55m2
Origin: ZhangJiaGang, China
After sales service: Engineers avaliable to service overseas
Qualification: CE, ISO9001-2008
The FILL-PACK tubular sterilizer will be wrapped well by PE film for surface protection and motor will be wrapped for waterproof
Wooden case will be covered then for long distance delivery
Main technical parameter
Item Technical parameter Item Technical parameter
Feed temperature 20-25℃ Sterilization temperature 105-110℃
Sterilization time 2-3min Discharge temperature 93-95℃
Model NJ-UHT Power consumption 40KW
Heat exchange area 55 square Inlet/outlet DN38
Pipe material, diameter 316L, φ38x2 Inlet/outlet of cooling water DN38
Outer pipe material, diameter SUS304, φ76x3 Cooling water consumption 5t/h
Company Contact:
- Phone: 051258643048
- Address: LeYu town,Zhangjiagang city,JiangSu province, China, Zhangjiagang , JiangSu , China
- Email:
- Website: https://www.fillpackmachine.com/
Published date: May 19, 2020
- Business Description: ZhangJiaGang City FILL-PACK Machinery Co.,Ltd. is loacated in Zhangjiagang city which is famous for beverage machinery producer collection.
Intergrated the industry advantange and its own development in R&D, production, sales, after sales service, FILL-PACK is ready to serve more and more customers with our full range products and satified service.
