New Technology Fingerprint Time Recorders With Built In Printer Ko P40 - China

New technology Fingerprint Time Recorders with built-in printer KO-P40

P40 is the latest fingerprint time attendance device with builtin thermal printer.

The 3'' TFT can display more information vividly,

including fingerprint image quality and verification result etc.

TCP/IP communication is standard and make sure the data transmission

between terminal and PC can be easily done within several seconds.

Function Features:

*Built-in thermal printer.

Automatically print attendance

*Records in real time when checking attendance

*High-precision real-time clock.

*TCP/IP, RS232/485\ communication function.

*Two USB HOST communication interfaces.

*Optional built-in ID/HID/Mifare card reader module.

Electrical Specifications and Functions:

*Power: DC12V3A

*Printing Method: Direct Thermal Printing

*Operating Temperature: 0~40 C

*The Maximum Diameter of the Printing Paper: 80mm

*Operating Humidity: 10~80%

*The Width of the Printing Paper: 58±0.5mm

*Back-up Battery Operating Hour: 1~2h

*Effective Printing Width: 48mm

*Time Error of the Lock: ±1min/year

*Printing Density: 6dots/mm, 288dots/line

*Retention Time of the Lack After Blackout: >3000h

*Printing Speed: <=35mm/sec.

*Register Capacity: 3000

*Record Capacity: 100000

Reliability:

*Printhead Life: 50km

*Mean Character Between Failures(MCBF): 15million lines

Use Condition:

*Printing 12 24 western characters, intermittently repetitive printing.

*The printed dots in every point line simultaneously can not exceed 25%, the longitudinal repetitive printing at the

same point in every character row can not more than 11 times

Company Contact:

• Posted By: KO TECHNOLOGY CO.,LIMITED

• Phone: 8602385268851

• Address: Huaqiangbei, luohu, , shenzhen , China

• Email:

• Business Description: KO TECHNOLOGY is a leading security company which was launched in 2005

  with main focus on worldwide business of security products, including

  access control, Fingerprint time clock, Face recognition System, smart

  card readers and smart cards, time attendance systems, etc.

  Based in the center of China and owns our own factories in Shenzhen, we are acting as the largest distributing and sourcing center of various of security products for customers, by owning abundant resources in security industry and years of professional experiences, we could provide reliable system with the most competitive prices, which will be your best option for relative products.
