Figure 400 Hammer Union - China

Figure 400 hammer union is designed of precision ball and cone sealing

surface, making the alignment easier.

And this kind of design ensures

reliable pressure seal.

It is recommended for manifold line connection.

And it is also suitable for pump suction and mud service.

It is also

used for sour gas.

It is threaded for pipeline and the butt weld is also

available.

It is often used for air, water, oil or gas service and its

cold working pressure is 4000 psi.

The test pressure is 6000 psi.

A figure 400 hammer union with black nut and red part.

Figure 400 hammer union.

A figure 400 hammer union is packed in a wooden box.

Figure 400 hammer union is packed in wooden box, making the transportation easier.

The details of figure 200 hammer union:

Cold working pressure: 4000 psi.

Test pressure: 6000 psi.

Special design of precision ball and cone sealing surface.

Recommended for manifold line connection.

Suitable for pump suction and mud service.

Also used for sour gas.

The specification of figure 400 hammer union

Part No.

Nominal pipe size Total length Countersink Nut radius Material Weight

nut subs lbs kg

HUF400- 01 2 50.8 5/ 3/ 16 131.8 1/ 4 6.4 3- 9/ 16 90.5 SF SF 11.0 5.0

HUF400- 02 3 76.2 6- 1/ 4 158.8 3/ 8 9.5 4- 3/ 16 106.4 SF SF 19.25 8.7

HUF400- 03 4 101.8 8- 1/ 8 206.4 3/ 8 9.5 5 127.0 SF SF 32.0 14.5

Note: SF = Forging steel.

If you are interested please contact us via sales at hammerunion dot org.
