Targeted Uv Phototherapy Xecl 308 Nm Excimer Laser For Vitiligo Psoriasis - China

The 308-nm excimer lamp advances selective phototherapy, for Psoriasis and vitiligo.

Advantages of the 308-nm excimer lamp The excimer lamp emits a wavelength of 308 nm produced using xenon and chlorine gases.

Induced rates of repigmentation is higher than with narrowband UV-B.

and moreover the selectivity of the treatment prevents irradiation of healthy skin and limits unsightly tanning of surrounding skin.

This method provide with many advantages over conventional phototherapies.

High fluencies are possible, which can be useful in thick plaques of psoriasis.

It is also possible to selectively turn the beam of light and thus to treat the specific area involved, sparing healthy skin.

It is easier to reach areas that are usually difficult to treat, such as mucosa.

The use of a monochromatic wavelength of 308 nm gives photobiological effects theoretically superior to those provided by NB-UVB, Stimulation of melanocyte migration and proliferation from progenitor niches located in hair follicles is certainly the major factor.

This stimulation is due to the direct action of UV on melanocytes but also to the action of cytokines secreted by keratinocytes.

Applicable symptoms:

1 - Psoriasis

2 - Parapsoriasis

3 - Vitiligo

4 - Relapse eczema

5 - pityriasis rosea

6 - atopic dermatitis

7 - palmoplantar pustulosis

8 - alopecia areata

9 - chronic skin ulcer

10 - granuloma fungoides

11 - pruritus cutanea Feature: XeCl single wavelength excimer light source, pure light, high energy, less side effects, effectively reduce the treatment cycles； Good targeting, no harmless to normal skin, easy to treat the lesions where the traditional light hard to reach； The light port is designed with special filters to screen out the useless stray light, ensure safety and reliability as well as easy observation of operator； Treatment handle works with multi-specification-avail able shading sheet, realized a precise control of the irradiation range, suitable for different sizes of lesion treatment； Treatment handle and the machine body split design, to minimize the weight of handle to maximum, make the operation more flexible, light weight； 8＂touch screen combined with humanized GUI design, make the operation more concise and fluent； Built-in minimum erythema dose(MED) test function, one machine for multiple use； Dose and time two kinds of work mode； Quick start, one key output, easy to operate； Built-in patient information management, convenient for operator to manage patients’ information and treatment records； External storage device for exporting and viewing user information； Small size, low cost of consumables, more suitable for home use； The optional timing chip offer multiple modes of selling and cooperation.

(optional function) Technical Parameter: Safety Classification Class I, B type for application section Operation Mode: Continuously Operation Power Supply: AC220V±10% 50Hz±2% (output：AC100-240V, 50/60Hz) Rated Power: 160VA Working environment Temp：5～40℃ Weight N.W.：5 kg Display Mode 8” color touch screen Output Waveform: XeCl excimer light Irradiation Mode Hand-held irradiation Irradiation Area 20cm2±1cm2 UVB Wavelength 290nm～320nm / output value: 308nm Irradiation intensity: 45 mW/cm2 Dose setting range 0~6000mJ/cm2 Time setting range 0~3min Lift time of light source ≥500 hours
