Double Door Pulse Vacuum Sterilizer - China

HA-WG Series Pulse Vacuum Autoclave Sterilizer – AJA GROUP

Model: HA-WG250, HA-WG360, HA-WG600, HA-WG800, HA-WG1200, HA-WG1500, HA-WG2000, HA-WG2500

Capacity / Volume: 250 liter, 360 liter, 600 liter, 800 liter, 1200 liter, 1500 liter, 2000 liter, 2500 liter

Main Features:

-- The main body is with horizontal rectangle double layer structure, the inside chamber is made of AISI 304 stainless steel, the outer layer is made of the brushed decorative sheet, and the there is motorized door or sliding door for choose, pneumatic sealing, and the door interlocking are strictly in accordance with the GSSD required.

-- The control system: Adopt the Siemens PLC and Siemens touch screen.

-- The piping system: Adopt with the reliable Germany Burket or GEMU pneumatic angle type valve, water ring pump and 0.22µm high efficiency sterile medical grade filters, the pipe clamp adopts the quick connectors, the piping and the related spares are all according to the sanitation standard.

-- With Germany Simens PLC platform independent research and development, human-Machine Interaction, convenient for operation.

-- Software design and manufacture products in strict accordance with the technical requirements for the sterilization process.

-- The Operating authority is divided into three levels to the manager, the technologist, and the operators.

-- Program interlocked, by the program is running, the sealing door can not be open.

-- All the alarm and the technical figures can be recorded and print.

-- If the inner chamber is higher than the safety pressure, the door can not be open.

-- Perfect product safety protection measures, 4 level emergency treatment of abnormal state.

-- Standard full stainless steel Trolley (600L to 2500L), Air Compressor, Built-in Steam Generator / Printer / Vacuum Pump.

-- Free Installation Guidance / Technical Support when need, 1 Year Quality Guarantee, After-Sale Service for life.

Company Contact:

• Posted By: Anhui Jin'ao Group Co., Limited

• Phone: 86-15357421367

• Address: No. 760 South Ma'anshan Road, Hefei , Anhui , China

• Email:

• Business Description: AJA Group is a professional manufacturer of Medical Equipment & Lab Equipment such as Autoclave, Sterilizer, Drying Oven, Lab Incubator, Vein Finder, Surgical Operating Light, Hospital Bed and so on.
