Synoptophore For Eye Diagnosis - India

Synoptophore for eye diagnosis

introduction

it is an equipment which is being used for diagnosing imbalance of eye muscles and treating them by orthoptic methods.

all the standard measurements and treatments are possible on this instrument including assessment of the angle alpha, the objective angle, abnormal retina correspondence, cyclophoria, hyperphoria and horizontal vertical vergences.

an automatic flashing unit allows each eye to be stimulated alternately or simultaneously.

manual flashing switches and independent dimming rheostats are provided as standard.

after images are achieved by using high intensity halogen light sources and condensing systems.

a pair of removable haidinger's brushes motor units are included, which allows the user to employ pleoptic techniques to assess and treat eccentric fixation and abnormal retinal correspondence.

specifications:

movement of optical tubes:

horizontal : adduction + 50deg

abduction - 40 deg

vertical : hyper 30 deg

hypo 30 deg

torsional : incyclo 20 deg

excyclo 20 deg

slide illumination: -

by rheostat controlled 6v lamp for each slide.

after image illumination by 6v lamp

auto flashing: -

auto flashing of slide illumination either simultaneously or alternatively in rapid & variable modes

mode & mode selection:

five modes of slide illumination namely normal, flashing right, flashing left, flashing r+ l & auto flashing can be selected by a single selector knob.

dimensions: -

longitudinal : 30.3 cms

lateral : 25.5 cms

vertical : 36.5 cms

weight : 20 kgs approx.

power supply : 220 v ac or 110v

standard accessories: -

1 - haidinger brush - 1 pair

2 - slides - 10 pairs

3 - power cord, dust cover, spare 6v bulbs
