Shanghai Manufacture Hot Sale Promotion Indoor Full Color Led Curtain Screen - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

pitch indoor P2.5

Usage:

Indoor

Tube Chip Color:

Full Color

Display Function:

video, image, text, message and so on

Pixels:

2.5mm

Screen Dimension:

Customized Size

Name:

indoor full color led curtain screen

Other name:

Shanghai manufacture indoor full color led curtain screen

Brightness:

1000-1200cd/sqm

Certificate:

CE ROHS FCC CCC

Color:

Full-color

Pixel pitch:

2.5mm

Module size:

160*160

Life span:

100000hours

Application:

Square, Adervertising, Bank, Hall, Rent

Pixel density:

16000dots/sqm

Packaging & Delivery

Packaging Details:

indoor full color led curtain screen Packing: LED screen with Carton, Wooden box, Flight case

Delivery Detail:

Shipped in 15 days after payment

Shanghai manufacture hot sale promotion indoor full color led curtain screen Product Description Specification of indoor full color led curtain screen

No.

specs Indoor full color PH2.5

1 Pixel structure 1R1G1B 3in1, 2121

2 Pixel pitch 2.5mm 3 Pixel density 160000 dots/Sq.

m.

4 Luminance 1000-1200cd/Sq.

m.

5 Module dimension 160mm(W) * 160mm(H)

6 Module resolution 64 pixel(W) *64pixelmm(H)

7 Module weight 270g

8 Cabinet dimension 480 * 480mm or other

9 Cabinet area 0.23 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 2.5m

12 Visual angel 140 degree (H/V)

13 Max power consumption 1125w /Sq.

m.

14 Average power consumption 563w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/32 dynamic scan, constant current

17 Input voltage AC 110~240 volts

18 Operation temperature -40° C~ +60° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
