New Supreme Quality P5 Led Module Light Smd - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

outdoor SMD P5

Usage:

Outdoor

Tube Chip Color:

Full Color

Display Function:

video, animation, message, images, word and so on

Pixels:

5mm

Screen Dimension:

Customized

Name:

p5 led module light smd

Other name:

new p5 led module light smd

Application:

Live Events Led Display

Color:

Full-color

Brightness:

6500cd/sqm

Certificate:

CE ROHS FCC

Product name:

Outdoor P5 SMD full color led display screen

Warranty:

2years

Module size:

160mm*160mm

Power Supply:

Meanwell

Packaging & Delivery

Packaging Details:

p5 led module light smd Packing: pearl wool + carton + wooden case or flight case

Delivery Detail:

Shipped in 15 days after payment

New Supreme Quality p5 led module light smd Product Description

Specification of p5 led module light smd

No.

specs outdoor full color PH5

1 Pixel structure SMD, 2727

2 Pixel pitch 5mm 3 Pixel density 40000dots/Sq.

m.

4 Luminance 6000cd/Sq.

m.

5 Module dimension 160mm(W) * 160mm(H)

6 Module resolution 32 pixel(W) *32pixelmm(H)

7 Module weight 240g

8 Cabinet dimension 800 * 800mm or other

9 Cabinet area 0.64 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 5m

12 Visual angel 140 degree (H/V)

13 Max power consumption 1800w /Sq.

m.

14 Average power consumption 900w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/8 dynamic scan, constant current

17 Input voltage AC 110~240 volts

18 Operation temperature -40° C~ +60° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
