Made In Shanghai China High Definition Led Round Display Advertising Full Color - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

floor indoor P6.25

Usage:

Indoor

Tube Chip Color:

Full Color

Display Function:

video, image, text, message and so on

Pixels:

6.25mm

Screen Dimension:

Customized Size

Name:

led round display advertising full color

Other name:

led screen

Brightness:

≥1000cd/Sq.m.

Certificate:

CE ROHS FCC

Color:

Full-color

Pixel pitch:

6.25mm

Module size:

500*500mm

Life span:

100000hours

Application:

Square, Adervertising, Bank, Hall, Rent

Pixel density:

25600dots/Sq.m.

Packaging & Delivery

Packaging Details:

led round display advertising full color Packing: Carton, Wooden box, Flight case

Delivery Detail:

Shipped in 15 days after payment

Made In Shanghai China High Definition led round display advertising full color Product Description

Specification of led round display advertising full color

No.

specs full color PH6.25

1 Pixel structure 1R1G1B 3in1, SMD3528

2 Pixel pitch 6.25mm 3 Pixel density 25600dots/Sq.

m.

4 Luminance ≥1000cd/Sq.

m.

5 Module dimension 500mm(W) * 500mm(H)

6 Module resolution 80 pixel(W) *80 pixelmm(H)

7 Module weight 400g

8 Cabinet dimension 500 * 500mm or other

9 Cabinet area 0.25 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 7m

12 Visual angel 120 degree (H/V)

13 Max power consumption 800w /Sq.

m.

14 Average power consumption 400w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/9 dynamic scan, constant current

17 Input voltage AC 95~256 volts

18 Operation temperature -10° C~ +50° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental installation available

27 IP Grade IP31

Company Contact:

• Posted By: Shanghai Ledlord Optoelectronice Co., Ltd.

• Phone: +86 021 60709506-820

• Address: No.5239 Beisong Rd, Songjiang district., Shanghai , Shanghai , China

• Email:

• Website: http://www.ledlord.cn

• Business Description: Shanghai Ledlord Optoelectronic Co., Ltd. is a high-tech enterprise, committed to LED display R&D, manufacturing, sales, installation, debugging, service and providing customers with a complete set of solutions and OEM services.

  With years of experience, Ledlord has been one of the most trusted led manufacturers in East China.

  In the future, Ledlord will face the global market, which has been exported to South Korea, India, Spain, Russia, Guatemala, Singapore, Turkey, the United States, etc.

  The products include advertising, bank, real-estate, stadium, exhibition hall, curtain wall, leasing and so on.

  Ledlord has professional engineering and technical R & D group, who continuously carries on product development and production process improvement, providing customers with the most competitive product.

  With the guide of business philosophy "criterion, innovation

  concentration" , Ledlord has got more than tenpatents technologies.

  Ledlord comprehensively enforces international management.

  All products have been through the high and low temperature, dust proof, waterproof and vibration test.

  Outdoor products have been reached IP66 or above standards.

  Ledlord Electronics LED display is the guarantee of industry quality and confidence, who strictly improves the Quality Management System on the basis of the quality system ISO: 9001: 2008 - Ledlord products have passed CCC, CE, FCC and RoHS certifications, which highly ensure the LED products reliable performance and customers high quality requirements.
