Factory In Shanghai China Trade Assurance Stadium Rental Led Display - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

rental indoor P4.81

Usage:

Indoor

Tube Chip Color:

Full Color

Display Function:

video, image, text, message and so on

Pixels:

4.81mm

Screen Dimension:

Customized Size

Name:

stadium rental led display

Other name:

factory in Shanghai China stadium rental led display

Brightness:

1200cd/Sq.m.

Certificate:

CE ROHS FCC

Color:

Full-color

Pixel pitch:

4.81mm

Module size:

250*250mm

Life span:

100000hours

Application:

Square, Adervertising, Bank, Hall, Rent

Pixel density:

43000dots/Sq.m.

Packaging & Delivery

Packaging Details:

stadium rental led display Packing: Carton, Wooden box, Flight case

Delivery Detail:

Shipped in 15 days after payment

Factory in Shanghai China Trade Assurance stadium rental led display

Product Description Specification of stadium rental led display No.

specs rental indoor full color PH4.81

1 Pixel structure 1R1G1B 3in1, 2121

2 Pixel pitch 4.81mm 3 Pixel density 43000dots/Sq.

m.

4 Luminance 1200cd/Sq.

m.

5 Module dimension 250mm(W) * 250mm(H)

6 Module resolution 52 pixel(W) *52pixelmm(H)

7 Module weight 400g

8 Cabinet dimension 500 * 500mm or other

9 Cabinet area 0.25 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 5m

12 Visual angel 140 degree (H/V)

13 Max power consumption 800w /Sq.

m.

14 Average power consumption 400w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/13 dynamic scan, constant current

17 Input voltage AC 110~220 volts

18 Operation temperature -10° C~ +50° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental installation available
