Socket Weld End Gate Valve - China

Socket weld end valve for boiler feedwater and steam is a kind of wedge disc valve, they are widely used in boiler feedwater and steam system in power plant .

The valve are desinged for higher temperature and pressure .

They are a kind of forged steam valve .

BENEFITS 1 - The wedge structure of the valve plate makes for large loading coefficient of the sealing.

Safe and reliable, so this wedge gate valve can be used under high pressure.

You can installed the valves in higher pressure less than class 1500 ; 2 - Socket weld end gate valve can be installed in less than 550 degree temperature medium .

3 - The high precision of the valve stem realizes the tight integration with stuffing .

So, medium leakage can be avoided.

4 - Hard alloy is used in the sealing surface, which are abrasion proof, erosion proof and has features of good abrasion resistance, reliable sealing and long service life.

SPECIFICATION Design and manufacturing standard: API 602 Face to face dimension standard: ASME B16.34 End connection standard: ANSI B16.11 Test Standard : API598

Size: 1/2"~2 "

Pressure: Class 1500

Body material: F11

Sealing material: Hard alloy

Connection type: Socket Weld End

Driving method: Manual APPLICATION Petroleum, chemical industry, electric power, water supply and drainage, City construction, steel industry, pharmacy industry, metallurgy industry
