Din Tilting Check Valve - China
price: 54.00 Dollar US$
Specification Details Design Std: EN 12334
Size: DN200--DN1600
Body, bonnet: EN-GJL-250 CAST IRON (GG25)
Pressure Rating: PN10, PN16
COATING: EPOXY ELECTRO STATIC POWDER
Face to Face: EN 558 Seri 14 / DIN 3202 F4
FLANGED: EN 1092-2 / ISO 7005-2
Pressure Testing: DIN EN593/DIN EN12266-1
Working temperature: -10°C to +150°C
Valve Description Tilting Check Valve, while allowing the flow moving to the desired flow direction, stops the flow when exposed to back flow, With the start of movement at defined flow direction on the system, the disc leaves the flow section by turning in its axis and allows the flow pass.
Company Contact:
- Posted By: Zhejiang Wanda Valve Co Limited
- Phone: +8657181370072
- Address: Gaoxin Avenue, Yongqiang Rd. Longwan Area, Wenzhou, China, Wenzhou , Zhejiang , China
- Email:
Published date: December 1, 2017
- Business Description: Wandavalve is one of the most important manufacturers of water valves in the China with experience dating back over 20 years.
Its success story began in 1994 when Steven Li founded a small workshop in Wenzhou, China.
Presently, the scope of Wanda Valve supply products including following(but not limited below): -
Wafer butterfly valve, Lug Butterfly valve, Flanged Butterfly valve
Resilient seat gate valve, Metal seat gate valve
Cast Iron Ball Valve, Cast Steel Ball valve, Stainless Steel Ball Valve
Cast Iron Globe Valve, Cast Steel Globe valve, Stainless Steel Globe Valve
Cast Iron Check Valve, Cast Steel Check valve, Stainless Steel Check Valve
DIN Y Strainer, ANSI Y Strainer
Our products are widely used in the irrigation, potable water and waste water systems and infrastructure equipment fields, oil gas, chemicpetrol etc.
