3V120-06 Directional Control Valve

Product Description

High Flow Rates: Designed to handle high flow rates, ensuring efficient operation in various applications.

Robust Construction: Durable build to withstand challenging industrial environments.

Double or Single Solenoid Operation: Options for either double solenoid for bistable operation or single solenoid for spring return functionality.

Multiple Mounting Options: Can be base mounted, sub-base mounted, or manifold mounted for flexibility in installation.

Manual Override Option: Often includes a manual override for troubleshooting or manual operation in case of power failure.

Parameter

Mode 4V110-M5 4V120-M5 4V130C-M5 4V130E-M5 4V130P-M5 4V110-06 4V120-06 4V130C-06 4V130E-06 4V130P-06 4A110-M5 4A120-M5 4A130C-M5 4A130E-M5 4A130P-M5 4A110-06 4A120-06 4A130C-06 4A130E-06 4A130P-06

Type 5/2 5/3 5/2 5/3

Flow rate 10mm2(Cv=0.56) 7mm2(Cv=0.40) 12mm2(Cv=0.67) 9mm2(Cv=0.5)

Model 3V110-M5 3V120-M5 3A110-M5 3A120-M5 3V110-06 3V120-06 3A110-06 3A120-06

Type 3/2 3/2

Flow rate 10mm2(Cv=0.56) 12mm2(Cv=0.67)

Connection ports Inlet = Outlet = Exhaust = M5x0.8 Inlet = Outlet = Exhaust = G1/8"

Media Clean air

Working type Pilot

Working pressure 0.15 ~ 0.8MPa
