Bi Directional Sealing Metal Seated Butterfly Valve - China

Bi-directional Sealing Metal Seated Butterfly Valve is a high performance butterfly valve used in the condition of two-directional sealing service, such as circulating water system, heat-supply pipe network etc .

It combined the benefits of ball valve and butterfly valve, and replace the triple offset butterfly valves in most of situation.

BENEFITS 1 - Designed with bidirectional sealing structure, the installation of the bidirectional rotary ball valve will not be restricted by the direction of the fluid.

2 - Since the metal seated butterfly valve is offered with self-sealing device, reliable sealing performance can be realized under the pressure from medium.

3 - Tight sealing, especially suit for the non-clean medium which include the particle water .

4 - Really metal seated butterfly valves, not the multilayer sealing tructure of triple offset butterfly valves.

5 - Ball valve's sealing performance, butterfly valve 's dimension 6 - Large size can be made, the max size can reach up to DN3000 - 7 - Easy to operate and maintenance TECHNICAL SPECIFICATION Body material : WCB Sealing material: Hard alloy Connection type: Flange Operating type: electric Size : DN100-DN3000

Pressure: PN10 APPLICATION : Municipal Engineering Circulating water system Water treatment system Heat-supply pipe network

Fire extinguisher system
