Titanium Knife Gate Valve - China

Titanium knife gate valve Titanium gate valve

Gate valve

Industrial valve

Technical Specification

Design Standard: API, ASME, EN, ISO, JIS, DIN, BS, GB

Connection type: Flange, Wafer, Lug

Pressure range: 150LB, 1.0MPa~25.0MPa

Size range: NPS3/8”-40”, DN10~DN1000

Drive: Hand wheel, Gear, Electric, Pneumatic actuator Design Feature:

Titanium knife gate valve is designed specifically for reliable in difficult services in pulp and paper mill, petrochemical industries, mining ect.

application.

This type valve is with optional seats and can be specially designed with electric, pneumatic actuation based on the local control, which facilitates automatically operation.

1 - Designed with wafer type structure, shorter face to face dimension, small volume, light weight.

It is convenient for installation, carriage, storage and piping layout.

It’s cost-effective valve.

2 - Packing seal use Japan DAKIN PTFE.

3 - The knife shape gate can easily cut off materials, fibers and sundries, preventing clogging and easy for closure and open.

4 - Replaceable seat make sure easy for repairing.

5 - Designed with straight type, small flow resistivity and more safe application.

6 - Handwheel with anti-corrosive plastic coating, which obtains good look and convenient for handle

7 - The complete round port area provides maximum flow capacity and minimum head loss.

8 - Operation: Hand wheel, Gear, Pneumatic, Hydraulic, Electric actuator Main Part Material :

Titanium Gr2, Titanium Gr3, Titanium G5, Titanium Gr6, Titanium Gr7, Titanium Gr12

Titanium GrC2, GrC3, GrC5, GrC6, Ti-Pd7B, GrC12

Titanium GrF2, GrF3, GrF5, GrF6, GrF7, GrF12

Company Contact:

• Posted By: Weidouli Valves Co.,Ltd

• Phone: 86-577-86921659

• Address: No.20,Xingyu Road,Airport Industiral Zone,Wenzhou City,Zhejiang Province,P.R.China, Wenzhou , Zhejiang , China

• Email:

• Website: https://www.wsv-valve.com

• Business Description: Weidouli Special Valves(WSV), Chinas leading valve manufacturer, specialize in industrial valves production, research & development, sales and service.

  History

  Founded in 1989

  Factory

  1st Factory: 9500m2

  2nd Factory: 33600m2

  People

  160 staffs

  Quality

  (DNV) ISO9001, ISO 14001, OSHAS 18001, API 6D, API 607/6FA, CE , TS etc.

  approvals.

  Equipment

  Over 100 sets including CNC and multi-station, Vacuum welding equipment, Vacuum heat treatment furnace, Vacuum surface modification.

  Test equipments

  such as NITON XRF Alloy analyzer, Direct reading spectrometer, Metallurgical microscope, Ultrasonic thickness measurement, Burawoy hardness test, Nondestructive test etc.

  Specialty

  Entirely focused on industrial valves for severe services

  Product line

  WSV Valves are built in high corrosion resistant performance materials: duplex and super duplex, titanium alloy, nickel alloys (Hastelloy?, Incoloy?, Inconel?, Monel?, Alloy 20, etc.

  ), zirconium and corrosion resistant alloys across all major industrial applications.

  Our products includes ball, gate, check, globe, butterfly, plug, control etc.

  valves

  Application

  Valves are delivered worldwide to the chemical engineering, mining project, metallurgy,

  pulp and paper making, power generation, natural gas and offshore and onshore other specific demand applications.
