Manufacturer Supply Inflatable Rubber Dam To Pakistan - China

Water Filling Rubber Dam 1 - Product Introduction Rubber dam is long tubular-shaped fabrics placed across channels, streams and weir crest to raise the upstream water level when inflated.

The membrane is a multi-layer fabric made of synthetic fibre which may be rubberized on one or both sides, and possibly coated with plastic film.

The fabric is quite flexible and yet exhibits very large resistance characteristics.

In open channels, they are used to divert water for irrigation, for raising existing dams, for flood control ling.

Other applications include remedy measure to prevent dam overtopping and control of chemical spills in streams.

2 - Features Low project cost (usually reducing investment 30%-70%)

Easy transportation and installation, convenient construction, shorter construction period

Dam span is flexible

Pier in the middle is less, easy - to -flood

Excellent anti-seismic and anti-crack performance

Stable regulating and controlling water level, easy to operate, running in safety

Fast in water filling and drainage

Well self-excretion on deposition from upstream and downstream Dam bag model Dam height(m) Internal pressure ratio(m) Safety factor(k) Width of foot piece(m) Perimeter of dam bag(m) Thickness of dam bag(mm)

ETA-RD1.0-100-2 1.0 1.60 29.1 1.80 3.69 6.5

ETA-RD1.5-100-2 1.5 1.55 13.5 2.55 5.33 6.5

ETA-RD2.0-100-2 2.0 1.50 8.00 3.37 7.01 6.5

ETA-RD2.5-100-2 2.5 1.45 8.60 4.50 8.96 7.0

ETA-RD3.0-100-2 3.0 1.40 8.70 5.55 10.78 8.0

ETA-RD3.5-100-2 3.5 1.35 8.60 6.77 12.72 8.7

ETA-RD4.0-100-2 4.0 1.31 8.00 8.31 14.83 9.6

ETA-RD4.5-100-3 4.5 1.30 8.30 9.25 16.68 11.5

ETA-RD5.0-100-3 5.0 1.25 7.70 11.11 19.08 12.0

ETA-RD6.0-100-3 6.0 1.25 7.47 13.17 22.74 14.0
