Jian Feng Expansion Joints In Concrete Roads - China

I

Q: What's the expansion joint?

A:

It is a structural joint along the vertical direction of the proper part along the length of the house to prevent structural cracks or damage that due to climate change (temperature of the thermal expansion and contraction).

II

Q: What are the characteristics of TST expansion joint ?

A: The following are the characteristics of TST expansion joint :

1 - TST is a kind of high visco elastic plastic material.

It is elastic and plastic at room temperature.

After high temperature melting, it can be poured into the gravel, and like asphalt concrete after molding.

It can bear the load of the vehicle, and it is elastic.

2 - Simple structure.

TST crushed stone paved directly at the bridge joints, And the formation of the continuous bridge deck pavement, and bridge deck level seamless.

The elastic joints can absorb various aspects of deformation and vibration, smooth running, comfortable, no noise, vibration.

3 - Convenient and quick construction.

After cooling, there can be open to traffic.

When the expansion joint needs to be replaced, there can be half edge construction.

The traffic on the busy road is not interrupted.

4 - Joint and bridge deck pavement, good sealing and waterproof, And the cost is low and durable.



III

Q: What is the principle of TST expansion joint ?

A: The so-called "elastic joints" is a kind of viscoelastic material to do the joints, so that the joints have a certain elastic deformation to adapt to the deformation of the structure.

IV

Q: What's the scope of application of TST expansion joint ?

A:

TST expansion joints can be used throughout the country.

Due to the high temperature adhesion characteristics of TST, at construction time, it can be firmly adhered to the existing road and fast.

Room temperature is not sticky, and after cooling will not be taken away .

V

Q: What are the installation methods of TST expansion joint ?

A: The following are the installation methods of TST expansion joint :

1 - Clean the notch, so as to achieve the design of width and depth.

Clear steel bar which interference displacement box buried, and the opening of the reserved hole must be greater than the width of the installation of the expansion joint.

2 - Check whether the gap between the various beams of the expansion device meets the requirements of the installation temperature, otherwise, Horizontal jack and jig should be used to adjust to meet the design requirements.

Adjusted good, immediately install special fixture.

3 - Set the lifting device according to the center position of the expansion joint.

The expansion device is arranged in the notch, The top surface of the expansion device should be the same as the deck elevation.

At the same time pay attention to the aspect and slope should also be consistent with the deck.

4 - After the expansion device is suspended in the reserved slot, the center line of the TST expansion joint should be aligned with the center line of the reserved gap of the top of the beam.

5 - To adjust the straight line segment of the expansion device.

And the gap of each longitudinal beam should be uniform.

6 - In the telescopic device box or the anchor plate, weld with more than Ф16 to high positioning in the vertical direction and weld a steel bar with Ф16 to wide positioning.

7 - After telescopic device being in place and anchorage, welding anchor bar and reserved steel bar to ensure that the extension device is fixed and flat.

8 - If the expansion device is installed sectionally, seams must be welded.

Welding shall be carried out by professional personnel.

And then anchored the joint.

9 - According to the size of the joint and reserved slot seam make the template, the template in place should cover tightly, to prevent water flowing into the tank displacement.

Expansion joint upper plane plus cover plate, to prevent mortar falling into the rubber sealing belt.

After checking whether the correct flatness of the device and midline position and the crevice meet the requirements or not.

If its meet the requirements, you can pour concrete and fully vibrating compaction of concrete.

Pay particular attention to displacement box and the reserved box can not leave empty.

10 - After the expansion joints of concrete reaching 80% of the strength, expansion joints can withstand external loads.
