Introduction of Hydrophilic water stop

Hydrophilic water stop is made from water-swelling rubber water line to

the basis of the ordinary rubber water-stop.

The product will swell when

contacted with the structures.

As a result, the tightness is fastened between the

water stop and water-proof performance is improved and the problem of circle

seepage which puzzles people in a long time is solved.

This series of products

have been used widely in some key projects and have gotten excellent results.

Features of Hydrophilic water stop

Waterproof wire adopted water-swelling rubber which will be self-swelling

when contacted with water.

So under the function of waterproof wire, the

concrete and water can seal better, and waterproof performance can be more

excellent.

The sections divided into high-strength area, water-proof area and the

installation area can take unequal thickness structures according to the unique

function of every area.

So each part of the sections can get uniform and

reasonable force.

Telescopic holes' outer wall is plane; formwork folder system

contact surface is large in construction and difficult to dislocation.

Setting hole

designed on the installation area is convenient to fix with the nearest steel bar, difficult to move, construction easily and install firmly.

Applications of Hydrophilic water stop

It can be widely applied to various types of concrete structures, such as: Dams, reservoirs, subway, culverts, tunnels, and other underground works.

Physical properties of Hydrophilic water stop

Description Index

B S J Swellable strip

1 - Hardness ( Shore ) 60±5 60±5 60±5 42±7

2 - Tensile strength, Mpa ≥ 15 12 10 3.5

3 - Elongation at break, % ≥ 380 380 300 450

4 - Compression set % 70ºC×24h ≤ 35 35 35

23ºC×168h ≤ 20 20 20

5 - Tear strength, KN/m ≥ 30 25 25

6 - Brittleness temperature, ºC ≤ -45 -40 -40

7 - Hot air aging 70ºC×168h Hardness (shore) +8 -

Tensile strength, Mpa ≥ 12 -

Elongation at break, % ≥ 300 -- -

100ºC×168h Hardness (shore) -- -- +8

Tensile strength, Mpa ≥ -- -- 9

Elongation at break, % ≥ -- -- 250

8 - Resitance to ozone ageing50pphm: 20%, 48h Grade2 Grade2 Grade0

9 - Adhesion of rubber to metal With contact section in elastomer

10 - Expansion rate in volume, % ≥ 150

11 - Repeared water immersion test Hardness (shore) 3

Tensile strength, Mpa ≥ 350

Elongation at break, % ≥ 150

12 - Low temperature bending (-20ºC×2h) No crack
