Uhmwpe Pipe - China

UHMWPE Pipe

Ultra High Molecular Weight Polyethylene(UHMWPE for short)pipe is extruded out with 3.5~9.2 million viscosityaverage molecular weight material by extruding machine in high temperature and pressure situation.

The UHMWPE pipeline is widely applied in the fields of hydraulic reclamation, dredging, mine tailing, ash transporting and so on.

Tengyuan is specialized in producing UHMWPE Pipe, plastic floater, rubber hose, HDPE dredging pipe and Dredging Engineering Pipe, etc.

Welcome to contact us, you will be kindly replied in 8 hours and quoted in 24 hours after receiving inquiry.

Detailed Information:

Specification

Diameter(mm) 0.6Mpa 0.8Mpa 1.0Mpa 1.25Mpa 1.6Mpa 2.0Mpa Wall Thickness(mm)

65 7 8

89 7 9

96 8 9

108 8 10

110 8 10

130 8 10 12

140 8 11 15

150 9 12 15

159 8 10 12 15

168 8 10 13 16

180 8 10 13 16 18

185 8 10 13 16 20

200 9 10 13 16 20

205 8 10 13 16 20

219 9 11 13 16 20

236 10 12 14 18 22

250 10 12 15 19 23

273 9 11 13 16 21 25

280 9 11 14 17 21 26

300 10 12 15 18 23 27

315 10 12 15 19 24 29

325 10 13 16 19 24 30

350 11 14 17 21 26 32

377 12 15 18 22 28 35

400 12 16 19 24 30 36

415 13 16 20 25 31 426 13 17 20 25 32 536 16 21 26 32 560 16 22 27 33 630 19 25 30 37 652 20 26 32 38 710 21 27 34 800 23 31 38 P.S. Customized diameter, thickness, length, color, etc.

are available.

Tengyuan export dredge pipeline floats, dredge hoses, Polyethylene Pipe, HDPE Dredging Pipe, Drain Pipe Fittings, Poly Pipe, Floating Pipe, HDPE Pipe Floats and HDPE flange, etc.

We trust and respect each other with our customers, employees, suppliers and other stakeholders.

Features

HighWearResistance

UHMWPEhasthebestwearre sistanceamongalltheengine eringplastics.

Thehighermo lecularweightofthemateria l ensure thebetterwearresistanceof thepipeline.

Thewear resistance of UHMWPEpipeis4~6timeshighe rthanQ235carbonsteel pipe, 2.7timeshigher thansilicon-manganese13we arresistantsteel pipe and 3 times higher than HDPE pipe, which enables UHMWPE pipe to be ideal for sand and slurry discharging.

2 - High Impact Resistance and Ring Stiffness

The impact resistance of UHMWPE pipes is 2 times of PC, and 10 times of PTFE.

With good impact resistance, which could withstand the great water hammer impacts from various sands, muds and slurries;

3 - Low Coefficient of Flow Resistance, High Transmission Efficiency and Saving Pumping Costs

UHMWPE pipe has very smooth surface with low friction loss and high flow rate.

The manning roughness coefficient of UHMWPE pipe is 0.0065, while steel pipe is 0.012, which could greatly increase the transportation efficiency, saving pumping costs.

4 - Minimizing Maintenance Time and Costs

With superior wear resistance, the UHMWPE pipelines will have less rotation frequency, the pipeline replacement cycle will be largely prolonged, which efficiently minimize the total costs for the project.

With good anti-adhesion, the UHMWPE pipelines will not be easy to have scaling, so no need acid cleaning.

With good corrosion resistance, the UHMWPE pipelines will not need anti-corrosion treatment.

Flange Adapter HDPE, HDPE Tee, Pipe Floats, Rubber Suction Hose for sale.

5 - Lightweight and EasyInstallation

UHMWPE pipe is light weight and thedensityofitsmaterialis 0.945g/cm3, approximately one-half the weight of aluminum and one-eighth the weight of steel, which effectively reducing transportation, handling and installation costs.

The UHMWPE pipeline could be connected by steel flanges, easy to install and dismantle at the working sites.
