Galvanized Steel Flexible Metal Conduit Reduced Wall - China

Galvanized Steel Flexible Metal Conduit (Reduced Wall)

PRWG series is UL listed / recognized for full trade size.

The performances of flexibility, pull and impact resistance completely meet with UL1 standard.

Wiring protection in/on building, office, light fixture, machines, elevator, data center and etc., where demand UL listed and low fire hazard.

The Extra Reduced Wall type is especially used for office OA system or above ceiling.

Material：Galvanized Steel

Temperature Range: -50℃~+350℃

IP Rating: IP 40

Flexibility: High

RoHS Compliance: Yes

Certificate: UL, cULus, cURus

We specialize in producing Flexible Metal Conduit, including Liquid Tight Flexible Metal Conduit US, Flexible Metal Conduit Water Proof EU, Flexible Metal Conduit Low Fire Hazard EU, Flexible Metal Conduit EMI Proof-EU etc.

Welcome to contact us

Nominal Conduit Size (mm) Nominal Conduit Size (inch) Part Number ID (mm) OD (mm) Bending Radius (mm) Package / Roll (ft/m) Measurement(LxWxH mm)

— 5/16 PXRWG - 5/16 7.92 ~ 8.60 11.94 ~ 12.95 50 100 / 30.5 320 * 320 * 150

12 3/8 PRWG - 3/8 9.52 ~ 9.96 14.22 ~ 15.49 50 100 / 30.5 320 * 320 * 150

16 1/2 PRWG - 1/2 15.88 ~ 16.38 21.84 ~ 23.37 75 100 / 30.5 380 * 380 * 150

- 9/16 PXRWG-9/16 13.89 ~ 14.60 17.90 ~ 18.67 75 100 / 30.5 -

21 3/4 PRWG - 3/4 20.62 ~ 21.21 26.54 ~ 28.07 100 100 / 30.5 450 * 450 * 180

27 1 PRWG - 1 25.40 ~ 26.42 33.02 ~ 35.05 125 100 / 30.5 550 * 550 * 220

35 1 - 1/4 PRWG - 1 - 1/4 31.75 ~ 33.02 39.37 ~ 41.40 160 50 / 15.3 500 * 500 * 180
