Full-Automatic Pipe Bending Machine

Pipe Bending Machine

Model: SB-18CNC-3A-1S

(CNC: Full Automatic 3A: Electric Bending 1S: 1 Stack)

Max.

Bending Capacity: ￠18 (3/4”)×1.5mm

Bending Degree: 0-190°

Bending Radius: 10-80mm (for machine)

Min Bending Radius: R≥1.5D (for pipe)

Mandrel Length: 1800mm(can be customized)

Max.

Bending Speed: 180°/s

Max.

Rotating Speed: 360°/s

Max.

Feeding Speed: 1000mm/s

Bending Accuracy: ±0.05°

Rotating Accuracy: ±0.05°

Feeding Accuracy: ±0.05mm

SLS Full-automatic pipe bending machine equipped with PLC or IPC which manage Bending (Y), Feeding (X) & Rotation (Z) in a complete automatic cycle.

Bending (Y-Axis): Controlled by Servomotor or by Hydraulic.

Feeding (X-Axis): Controlled by Servomotor.

Rotating (Z-Axis): Controlled by Servomotor.

We only use popular quality components in the production of our benders from such companies as JAPAN MIYSUBISHI, TAIWAN WEINVIEW, JAPAN YUKEN, JAPAN NEIMICOM, SKF AND ETC.

This value priced CNC Tube Bending Machine is an excellent choice for general purpose and any type of conventional tube bending applications.

STANDARD

Interactive PLC touch screen offers easy access to auto and manual operating modes.

System diagnostics and multiple language capability.

Fully hydraulic clamping on clamp die and pressure die.

Bending Axis-Driven by Cylinder or Servo Motor, Feeding Axis-Driven by Servo Motor, Rotating Axis-Driven by Servo Motor.

Equipped with adjustable speed valve on pressure die ensures the synchronization of bending.

Air cooling system or water cooling system ensures the equipment long-time work stably under the high temperature.

CE&ISO 9001: 2000.
