Planetary Gearboxes Foot Mounted Flange - India

Planetary Gearbox: Mounting Type Foot/Flange- Model B201 To B904 &

B1002 To B1504

Bevel Planetary Gear Box: Mounting Type-Foot/Flange Model B 201b To B 904b

Agnee has developed Planetary Gearbox for various Industrial applications operated by Electric motor and Hydraulic motor.

Agnee providing customers with High Quality, Cost Effective, Power saving, Planetary gear box with wide range of power transmissions.

So feel free to become a privileged buyer and purchase for the most competitive prices offered by us.

Principle:

Planetary Reduction Gearbox consist of an Internal toothed Ring Gear to which are set 3 Planets mounted on the Planet Carrier engaging also with the Sun Gear (Pinion) and reduced output speed is taken through Planet Carrier and Ring Gear is remain stationary.

Output shaft maintaining the same direction of rotation as Input.

Salient Features Planetary Gearbox:

High Reduction Ratios, Power Saving, High Efficiency Long Life, Space-Saving Compactness, Higher Overload Capacity, Reliable and Trouble-Free Service, Compact and Co-Axial Sturdy, No-Self Locking Property.

Technical Specifications:

Reduction Ratio: 3.6 to 7000: 1

Output Torque: 10 Nm to 1, 450, 000 Nm

Input Power: 0.25 HP to 300 HP (0.18 Kw to 224 Kw)

Mounting Type: Flange/ Foot

Prime Mover: Electric Motor, Hydraulic Motor

Input Speed: 1440 rpm

Input Type: Male Shaft, Hollow Input

Output Type: Male Shaft, Hollow Input, Spline Shaft

Applications of Planetary gearbox:

Planetary gearbox has its application in Machine tools, Plastic Machinery, Goods & Personnel lifts, & Dockyard Cranes, Material handling equipments, Truck mounted mobile cranes etc.

Dredging Equipments, Road Making Machinery Sugar Crystallizers and mill drives.

Company Contact:

• Posted By: Agro Engineers

• Phone: 917442363799

• Address: E-3, Industrial Estate, Kota , India

• Email:

• Website: http://www.agroengineers.com

• Business Description: An ISO 9001: 2008 enterprise is focused in Manufacturing of Planetary

  Gearbox, Right Angle Worm Gearbox, Helical Gearbox, Bevel Helical

  Gearbox, Motorized Gearbox, Shaft Mounted Speed Reducers, Double

  Reduction Worm Gearbox, Bevel Helical Geared Motor, Inline Helical

  Geared Motor, Crane Hoist and Winches, Crane Duty Helical Gearbox.

  We

  are focused to provide a complete gear service, from design engineering

  and product development to complete manufacture and sales of gears,

  gearboxes and related power transmission mechanisms custom built as per

  specifications cater to almost every industry like Stone, Mining,

  Engineering, Cement, Fertilisers, Rayons, Textiles, Chemicals, Nuclear,

  Thermal, Hydro Electric Plants, Coal Handling Plant, Hydro multipurpose

  Projects, and host of other applications.

  We try to understand the

  problem of the customer who may be anywhere in the world and to provide

  him proper technical solution, product and services.

  Its, in 1999, the

  enterprise received its first export order for manufacture and supply of

  high precision Rack and Pinions to Ireland.
