1k101 Iron Based Amorphous Ribbon - China

1 Introduction It's an amorphous alloy consisting of 80%Fe, 20%Sic and B metals, formed by rapid solidification.

With high permeability, high saturation flux density, low loss and good stability, it can meet modern electronic product's requirements in high frequency, large current, miniaturization and energy saving, and also can replace silicon steel, permalloy and ferrite in electrical and electronic products.

2 Application Widely used in iron core for distribution transformer, medium frequency power transformer, inverter, high-power switching power supply, pulse transformer, magnetic amplifier, saturable reactor, PFC inductor, filter inductor and so on.

3 Feature High saturation flux density-- to reduce winding turns and product size

High resistivity, low coercivity-- to improve production performance

Low loss(equal 1/3 to 1/5 of silicon sheet)--to cool temperature, improve efficiency

Low excitation--to decrease no-load current, and noise

Variable permeability-- to suit for different application by different heat treatment process Good temperature stability--long-term operation under 130° C 4 Property Model : 1K101 Performance Index Rate Performance Index Rate

Saturation flux density Bs (T) 1.56 Saturation magnetostriction

λs 27*10^-6

Curie temperature Tc(℃) 410 Density d(g/cm^3) 7.18

Crystallization Tx(℃) 535 Resistivity ρ(Ωm²/m) 130

Hardness HV Kg/mm^2 960 Coercivity Hc(A/m) <4 5 Specification Item Width

(mm) Thickness (μm) Thickness error (μm) Lamination factor

spray strip1K101 100-220 25 ±2 >0.86

shear strip1K101 2-220 25 ±2 >0.86

Note: Normal width: 120, 140, 70, 213mm, the specifications can be customized.
