Shbd315 Hydraulic Butt Fusion Welding Machine - China

315hdpe pipe butt fusion welding machine

1 - apply to hdpe pipe

2 - hdpe pipe butt fusion welding machine

3 - high efficience

315mm pe hdpe butt fusion welding machine- - - Application:

PE pipes welding machine;

HDPE pipes welding machine;

PP pipes welding machine;

PB pipes welding machine;

any other plastic pipes available for welding.

.

.

.

.

.

315mm pe hdpe butt fusion welding machine- - - Further parameters:

Model

SHBD315

Welding range( mm)

90mm- 110mm- 125mm- 140mm- 160mm- 180mm- 200mm- 225mm- 250mm- 280mm- 315mm

Heating plate temperature

270°C

Heating plate surface

temperature( 170- 250°C)

<±5°C

Pressure adjustment range

0- 6.3MPa

Cross- sectional area of the cylinder

2000mm²

Working Voltage

220V, 60Hz

Heating plate power

3.1KW

Cutter power

1.36KW

Hydraulic station power

0.75KW

Total Power

5.21KW

N.

G.

163.50KG

Volume

1.2CBM

195KG

M.

G.

232KG

315mm pe hdpe butt fusion welding machine- - - Our advantages:

1 - The raw material of the machine frame is aluminum ZL104, it is light but strong, is one of the best material for machine.

2 - The main electrical apparatus elements are best of china, many are imported from abroads.

3 - Removable PTFE coated heater with separate temperature control system, the temperature can be controlled to a minimum range.

4 - The electric facer adopts reversible double cutting edge blades, which can make the cutting effect more perfect.

The main electrical components are imported from overseas, which are more reliable and stable, extend the life of welding machine and perform more efficiently.

Easy to use.

1 - Lower start- up pressure make the small diameter pipe weld more reliable.

2 - Welding position can transform that it is convenient for welding all kinds of pipe fittings.

3 - Standalone dual channel timer Can record both of heat and cooling hours, when timing is over, the timer will give an alarm.

4 - High- precision shockproof pressure gauge with large dial is easy to read.

Packaging & Shipping

Our machine will be spread a layer of oil, and then be wraped by plastic film, put into a wooden box at last.

This type of packages is avoid getting rusty easily.

Our Services

1 - One year warranty, life- long maintenance.

2 - In warranty time, if non- artificial reason damaged can take old change new for free.

Out of warranty time, we can offer maintenance service ( charge for material cost) .

3: Engineers available to service machinery overseas but all the costs to the buyer to pay.

Company Information

Jinan Bada Plastic Pipe Welding Equipment Co.

, Ltd is located in Jinan city, which is the capital of Shandong province.

It is a professional manufacturer for hot melt machine producing.

The main products are Bada series butt fusion welding machine, automatic butt fusion welding machine, pipe fitting welding machine, saddle- shaped taper pipe butt fusion welding machine, plastic pipe multi- angle cutting saw, PPR socket welder and other auxiliary building machines.

.

.

.

.

.

.

we are professional plastic pipe butt fusion welding manufacturer in china.

we can offer lower price but the great quality to serve our customers.

Welcome you to visit.

.

.

.

.

.

.

.

FAQ

The machine doesn' t work: 1, check whether the working voltage is normal

2, check whether the leakage switch is closed
