Portable Pkz 76 External Clamped Type Pipe Beveling Machine - China

Portable PKZ-76 External Clamped Type Pipe Beveling Machine

PKZ Outer Clamped Pipe Beveling Machine

Pipe Beveling and Cutting Machine 1 - The PKZ pipeline grooving machine is suitable for the Dia 27 -Dia76mm pipeline groove.

2 - The product is small in size, light in weight and easy to operate, and automatic feed is especially suitable for construction site work.

It is convenient to carry out the slope of the water wall tube.

3 - This product adopts external clamping mode, and has different static jaws according to the the outer diameter of the pipe.

These statics are accurate in positioning and easy to disassemble and disassemble.

4 - The movable jaw is V block, reliable clamping, suitable for all sizes.

The automatic feeding mode not only reduces the labor intensity of the workers, but also makes the processing process more stable.

5 - The cutter head is made of high quality cemented carbide and can easily process high quality alloy pipes.

6 - The original Metabo motor is used in the power industry, and its quality is superior.

PKZ-76 Pipe Beveling Machine Overview:

The PKZ pipeline grooving machine developed by Metals Kingdom Industry Limited is suitable for the Dia 27 -Dia76mm pipeline groove.

The product is small in size, light in weight and easy to operate, and automatic feed is especially suitable for construction site work.

It is convenient to carry out the slope of the water wall tube.

This product adopts external clamping mode, and has different static jaws according to the the outer diameter of the pipe.

These statics are accurate in positioning and easy to disassemble and disassemble.

The movable jaw is V block, reliable clamping, suitable for all sizes.

The automatic feeding mode not only reduces the labor intensity of the workers, but also makes the processing process more stable.

The cutter head is made of high quality cemented carbide and can easily process high quality alloy pipes.

The original Metabo motor is used in the power industry, and its quality is superior.

This product features: safe and reliable, high efficiency, can greatly reduce the labor intensity of workers, and improve the quality of groove.

Main technical parameters

Machining range: 27 - 76mm (diameter)

Feeding mode: automatic feeding

One loading card intake stroke: 18mm

The wall thickness of the first loading card: 12mm

Input power: 1100W

Input speed: 0 to 900rpm, 0 to 2800rpm

Power parameters: 220V/5.0A, 50 to 60Hz

Operating weight: 8Kg
