Laboratory High Voltage Electrostatic Separator - China

XDF ModelΦ250×200 High voltage Electrostatic Separator is mainly

applied for separation of conductor and non-conductor minerals and

classification of planting materials instead of screening operation as

well as food processing and seed selection.

serial number

item Number value unit

1 Drum tube（diameter×len gth） φ 250 × 200 mm

2 Drum drum rotational speed 50 ～ 300 r/min

3 corona electrode

（Pole wire diameter×quantity） ; 0.2 mm

1 ～ 5

4 static level

（diameter×quan tity） φ 30 mm

1

5 electrode control

Radial movement quantity 50 mm

Circumferential Angle 60 °

6 hairbrush（diameter × roll diameter

） φ 105 × 60 mm

7 Brush speed Drum speed 2 times

8 Drum tube heating temperature 50 ～ 60 ℃

power 900 W

9 Silo heating temperature 100 ～ 300 ℃

power 900 W

10 Opening the gate silo calibration 0 ～ 20 mm

11 Feeding chute Angle 0 ～ 30 °

12 Feeding chute vibrator FREE SIZE

13 Processing material particle size 0.04 ～ 1 mm

14 handling ability

15 ～ 30 Kg/h

15 High voltage power supply power 800 W

16 maximum voltage

60 Kv

17 overall dimension

920×1120×1850 mm

18 weight 400 Kg
