C10 C21 Double Deck Roll Forming Machine - China

Hebei Xinnuo double roll forming machine uses the newest

double design, one machine product two profiles.

This is

C10-C21 two profiles, all popular in Russia, Ukraine.

It

cover small area, easy to transport, cost savings.

Our

after-sales service is perfect, and we can special design

and manufacture according to user requirements, at the same

time, guide the users production, installation, debugging

and maintenance.

The client can choose any two profiles, we

can design the machine according to your requirement.

Equipment components: manual decoiler, main machine for

roll forming, forming cutter, hydraulic system, PLC control,

run-out tableMain parameters:

1 - Control System: Automatic PLC frequency control, text

screen

2 - Roller Steps: 10/14

3 - Main Power: 4kw

4 - Pump Power: 4kw

5 - Diameter of Roller: Φ80mm

6 - Productivity: 8-12m/min

7 - Feeding Width: 1250mm

8 - Effective Width: 1000/1000mm, tolerance ±1/100

9 - Thickness of the Plate: 0.35-0.8mm

10 - Dimension of Main Roll Former:

7600mm×1650mm×1450mm

11 - Roller Material: 45#steel by CNC-machined heat

treatment and buffing, and the thickness of surface plated

chromium is 0.05mm.

The debugging method of double roll forming machine

1, the first double roll forming machine two, after the

four corners of the line from frame exactly at the top of

the shaft height consistent amount, and then from the first

row to the last row, find a straightened wire, check,

whether under shaft in a straight line, under the axis of

left, right sides move into level.
