Vu140179 Slewing Ring Bearing For Excavators - China

VU140179 slewing bearing (without gear teeth, four point contact ball bearing)

d 124.5 mm

D 234 mm

H 35 mm

Ca 115 KN Basic dynamic load rating, axial

Coa 255 KN Basic static load rating, axial

Cr 75 KN Basic dynamic load rating, radial

Cor 114 KN Basic static load rating, radial

Mass 7 kg

BRS Four Point Contact Bearing Features:

1 - Consists of inner and outer rings with a closing plug and securing dowel, rolling elements, spacers, contact seals and lubrication nipples.



2 - Gear teeth on the outer ring, inner ring or without gear teeth.

3 - Bearing rings with through holes or threaded holes for fixing screws.

4 - Compact structure and light weight.

5 - Can support axial, radial and tilting moment loads at the same time.

6 - Professional Surface treatment such as blackening, galvanization(zinc-platin g, zinc coating), antisepticize, corrosion prevention, rotproof, antiseptic, anticorrosive painting, etc.

Ensure BRS Bearings function well under extreme working conditions.

Application: Rotary welding machinery, medium and small series crane and excavators etc.

To learn more about our company or get the Installation Instructions of VU140179 slewing ring bearing regarding the installation size, weight, basic dynamic load rating, load, limiting speed, and clearance, please contact us.

Drawing and sample are available upon request.
