Csxd120 Thin Section Open Ball Bearing With A 12 7mm - China

CSXD120 Thin Section Open Ball Bearing with a 12.7mm cross section width, CSXD120 bearing is a popular item that could be used in many applications, the dimensions are 304.8mm*330.2mm*12.7mm.

CS XD120 bearing has Brass balls retainer, CSXD120 bearing is oil preserved.

Item: CSXD120 Ball Bearing Type: Deep groove Radial Ball Bearing Material: Chrome Steel Cage: Brass Closures: Open Dimensions: 304.8mm*330.2mm*12.7mm ID (inner diameter)/Bore: 304.8mm OD (outer diameter): 330.2mm Width/Height/thickness: 12 .

7mm Cross Section: 12.7mm Dynamic load rating: 24200N Static load rating: 60000N Operating temperature min: -30°C Operating temperature max: 120°C Quantity: One Bearing Thin section bearings have very small cross-sections relative to their diameters.

This allows designs with smaller design envelope and lower mass, while achieving high rigidity and running accuracy.

In contrast to the rolling bearing series standardised in accordance with DIN ISO, in which the cross-section increases with the bearing diameter, all sizes of thin section bearings of one series have the same cross-section.

A larger cross-section can be selected in a graduated way and thus a thin section bearing with high load carrying capacity can be used without having to alter the shaft diameter.

Light and compact designs can be achieved with thin section bearings.

Thin section bearings are available as deep groove ball bearings, four point contact bearings and angular contact ball bearings.

The main areas of application are in handling devices, industrial robots, textile and printing machinery, medical and optical equipment and aerospace engineering.
