Stainless Pipe Induction Annealing Machine - China

Stainless Pipe Induction Annealing Machine' s Characteristics:

1、 Stainless pipe induction annealing machine' s quality: high- frequency quenching layer is too shallow.

Cusp at the easy to crack.

IF too easily quenched layer deformation.

I was the only audio device' s ultra- hardened rail is right, and the quenching level is moderate, fast, moving water way up to 400mm / min, quenching into a double track at the same time.

2、 Stainless pipe induction annealing machine audio compact, high power; easy to operate, mobile and flexible

3、 The same for machine tool gear, machine tool accessories and other top quenched.

4、 The sensor connection structure with soft, easy to tune the gap, guide wheel positioning to avoid ignition.

5、 The technology is mature, professional, experienced, and used by dozens of domestic machine tool factories.

Stainless Pipe Induction Annealing Machine' s Parameters:

Model: WH- VI- 40

Work Power: Three phrase 380V/ 50- 60Hz

Working Voltage Range: 342V- 430V

Max Input Current: 62A

Max output power: 40KW

Oscillation Frequency: 10- 40KHZ

Host Weight: 40kg±5% kg

Host Size: 460* 360* 630

Transformer Weight: 29kg±5% kg

Trandformer Size: 320* 320* 310

Cooling Water Pressure: 0.1- 0.3mpa

Temperature Protection: 50℃

Cooling Water Flow ( Host) : 15L/ min( 0.1mpa)

Cooling Water Flow ( Transformer) : 18L/ min( 0.1mpa)
