Tsbv Series Vertical Centrifugal Pumps Are Used For Onshore And Offshore Drilling - China

Sandman™ TSBV series Mission Magnum I type Vertical Centrifugal Pump is a single stage vertically mounted centrifugal pump, offers ease of maintenance as well as a small footprint in areas with limited floor space, the pump shaft directly connect the electric motor, there no need to install the bearings and mechanical seal, the concentric casing design minimizes shaft cyclical deflection and allows excellent slurry handling.

TSB Sand Pumps are 100% interchangeable with Mission Magnum pumps, It is designed and engineered to handle abrasive, viscous and corrosive fluids in drilling fluid or industrial slurry applications.

The pump performance is matched by exceptional performance, high volume, high temperature capabilities, long service life, ease to maintenance, overall economy and greater savings.

TSB series sand pumps are currently in operation on land-based and offshore drilling rigs around the world.

We will offer the best choice for the intended application, taking into consideration fluid conditions.

Design Features: • The TSB series concentric pump housings are heavier and stronger to outlast conventional pumps.

The housings are thicker for extra strength and extended service life.

The concentric design allows the distance between the impeller and the housing to be the same at all points.

The concentric housing eliminates turbulence and cavitation within the pump.

It also reduces the radial load on the bearings.

The full pipe diameter of the pump entrance.

The housing gasket is recessed to protect it from fluid leaving the impeller.

• The TSB series open-vane impeller eliminates recirculation that occurs in closed impellers.

The impeller is designed to reduce turbulence, lower radial and thrust loads, and provides a smooth flow of fluid through the pump.

Housing wear is reduced by eliminating the high scrubbing action that occurs on conventional pumps.

The SB240 series impeller is designed to allow fluid leaving the impeller to blend with recirculating fluid to reduce abrasive wear of the casing.

The open-vane impeller has no exposed impeller nuts or shaft threads.

The impeller is screwed on and the threads are protected by ano-ring.

The SB240 series pump and impeller are designed to increase service life many times over that of conventional pumps.
