Tobee® Thr10x8st High Quality Horizontal Centrifugal Slurry Pump - China

Tobee® 12/10 ST THR Rubber Lined Slurry Pump Performance Parameters: Model Max.

Power (kw) Materials Clear water performance Impeller Vane No.

Liner Impeller Capacity Q (m3/h) Head H (m) Speed n (rpm) Eff.

η (%) NPSH (m) 12/10ST-THR 560 Rubber Rubber 720-1620 7-45 300-650 80 2.5-7.5 5 Tobee® Rubber Lined Slurry Pumps Sealing Arrangement: Packing Seal As one of the most commonly used seals for rotating shafts, the packing seal can come with low-flush or full flush arrangement which uses flushing water to prevent media from escaping the pump housing.

This kind of seal is suitable for use under all pumping conditions.

In situations where corrosive solids or high temperature might be encountered, Teflon or aramid fiber is used as the packing material for the gland.

For high abrasion conditions, a ceramic shaft sleeve is available.

Centrifugal Seal - Expeller The combination of impeller and expeller creates the pressure needed to seal against leakage.

Together with the gland seal or lip seal which is used as the shut-down seal, this type of seal can handle sealing requirements for applications where full-flush gland seal is impractical due to lack of water on the site, or sealing water is allowed to enter inside the pumping chamber to dilute the slurry.

Mechanical Seal AHR rubber lined heavy duty slurry pump utilizes a leak-proof mechanical seal design which allows easy installation and replacement.

Other types of mechanical seal are among options to suit the slurry pump for various pumping applications.

We also utilize special ceramic and alloys of high strength and hardness on parts that are subjected to friction.

Unique design of and seamless fit between the mechanical seal and seal chamber provides excellent resistance to abrasion and shock that ensures its effectiveness under the toughest conditions.
