Tobee® 24024 X0 Hs Impeller For Mission 14x12x22 Centrifugal Pump - China

Sandman™ Mission 14x12x22 Centrifugal Pump Impeller 24024-X0-HS open vane impeller design is engineered to reduce turbulence, eliminate recirculation, lower radial and thrust loads, and provide a smooth flow of fluid through the pump.

Mission Magnum XP Blender Pump is ideally suited for pumping high volumes of heavy slurries that are abrasive, corrosive, and difficult to pump.

The compact overall dimensions make it an excellent choice for high volume mobile and stationary applications where a small footprint is critical.

High chrome alloy or hard iron material options for different applications.

Mission XP Centrifugal Pumps Main Parts: • Heavy Duty Pedestal – heavy duty frames are manufactured from cast iron for high strength and durability to withstand high piping loads.

• Casing – The Mission XP frac pump has been beefed up in critical wear areas for extra life.

The concentric housing eliminates vibration, turbulence, cavitation, and reduces bearing load and shaft deflection.

• Wear Plates – The Mission XP pump casing comes with replaceable wear plates.

This feature reduces the maintenance costs of housing replacement by merely replacing the wear plates.

• Shearing Ring- Mission XP pump offers a shearing ring option to convert a regular centrifugal pump to a shearing pump for special mud applications.

• Mechanical Seals – Mission XP pump takes pride in carrying one of the finest mechanical seals on the market, whether it be Tungsten-Tungsten, Tungsten-Silicone, or Silicone-Carbide.

They come with a highly polished sealing faced and with piton bellows and stainless steel springs.

• Pump Bearings – Mission XP pump uses nothing but the best and the finest bearings in its pumps.

The outboard bearing assembly consists of a pair of angular contact bearings with high thrust load ratings and zero end play.

The heavy duty inboard bearing is a double row ball bearing with high radial load ratings to compensate for the larger size impellers and heavy duty applications.

• Labyrinth Seals (optional) – Mission XP pump installs labyrinth seals by customer request in all its pumps to isolate the bearings from harmful contaminants while keeping bearings lubricated.

Company Contact:

• Posted By: Hebei Tobee Pump Co.,Limited

• Phone: +86-18132613960

• Address: shijiazhuang , shijiazhuang , 河北 , China

• Email:

• Website: https://missionmagnum.com/

• Business Description: Hebei Tobee Pump Co.,Limited

  That is a professional manufacturer in designing and manufacturing Centrifugal Slurry Pumps, Pipes & Fittings, Valves etc.

  Our factory is located in the High tech Development Zone, Shijiazhuang City, China.

  We specialized in Horizontal slurry pumps, Vertical slurry pumps, Gravel sand pumps, Dredging pumps, Paper pulp pumps, Molten Salt Pumps, End suction pumps, Double suction pumps, Multistage pumps, Boiler feed water pumps, Self priming pumps, Inline centrifugal pumps, Sea water pumps, Chemical pumps, Irrigation pumps, Fire pumps, API 610 centrifugal oil pumps, Submersible sewage pumps, Slurry Pump spare parts, Pipes & fittings and Valves in domestic and over 80 countries in the world.
