Tobee® 19121 Xx 30 Impeller For Mission Magnum I Pump 6x5x11 6x5x14 8x6x11 - China

19121-XX-30 Semi-open type Impeller is used for Mission Magnum I Pump 6x5x11, 6x5x14, 8x6x11 - Tobee® provides 19121-xx-30 impellers for Mission Magnum centrifugal pump 6x5x14: 19121-70-30 Impeller 6 x 5 – 11 inch

19121-80-30 Impeller 6 x 5 – 12 inch

19121-90-30 Impeller 6 x 5 – 13 inch

19121-A0-30 Impeller 6 x 5 – 14 inch Fully open impeller, best design for the chemical process industries services.

Ideally suited for corrosives and abrasives, handles solids and stringy fibers with ease.

Allows for simple restoration of clearances when wear takes place.

Back pump-out vanes reduce pressure on the shaft seal, reduce axial thrust on the bearings.

Part size cast into the impeller.

This makes part identification easier.

Impeller gasket in included with impeller

All impellers are dynamically balanced

Offered Hard iron and other materials upon request 19121-XX-30 Impeller for Mission All impellers are investment casted or resin-casted with pickling (acid washing) as our power-end parts, which are also available in cast steel in favor of ductile.

All other sizes are resin-casted with pickling (acid washing) to ensure smooth surface finish.

To ensure quality, we meticulously check threaded holes by fitting their bolts to ensure the threads are clean and clear.

All casings are of course pressure tested and all impellers and dynamic balanced.

Each casing is properly pressure tested prior to shipping.

Our impellers are comparable to famous pump brands such as NOV Mission Magnum® and MCM.
